Using the Beyerdynamic Classis RM30 with Phoenix Stingray

The Classis RM 30 is a desktop microphone for round table discussions, podiums,

tele/video conferencing and lecterns. The vertical microphone array results in a hor-

izontal corridor characteristic (horizontal cardioid, vertical lobe).

Microphone Sensitivity: 28.7 mV/PA

Dynamic Range: 107 dB-A

Require Phantom Power: 48V

Recommended Mic Sensitivity

Table Top: 34 dB

1) The microphone should be connected to the XLR to Terminal Block Converter (MT720) which is

then connected to the "microphone input" port of the Stingray.

XLR to Terminal Block Converter (MT720)

The Stingray's mixer should be assigned to the mic input. The setting can be selected either via the

device front panel or through the Stingray's setup GUI.

Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774

Table of Contents

Do you have a question about the Beyerdynamic Classic RM30 and is the answer not in the manual?

Page 1 Setting the Stingray The Stingray’s mixer should be assigned to the mic input. The setting can be selected either via the device front panel or through the Stingray’s setup GUI. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
Page 2 2) Scroll down to the second menu item which is the “automatic mixer selection”. 3) Select it, and in it select “mix microphone input”. Stingray GUI: 1) Select the primary unit and then click on “edit primary parameters”. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779...
Page 3 2) In the next screen you should select MIC MIXER. 3) Select the Microphone button to adjust microphone sensitivity. You can also view the micro- phone levels from this screen. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779...
Page 4 Stingray. Voice lift is not supported on Micro- phone Level. Solution • If Voice Lift is required, use a 48V Phantom Power adapter to connect to Line Level input. Beyerdynamics recommends the Whirlwind MICPOWER Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779...
