SUPA PEG
A U S T R A L I A
Awning Setup/ Fold Away Instructions
Thank you for your purchase of the Australian made and designed ERV STAND EASY
Please follow these few simple step by step instructions to make setting up your ERV
STAND EASY AWNING simple to use and to improve the life span of the product
**Please note: two people maybe required to set up and pack away in winds
over 5 knots or for unexpected wind gusts if the supply tie down straps are
• Mounting Bracket Set (2 Brackets) ) - 13mm Spanner
• 4 x 225mm Galv Tent Pegs Pegs - Stainley knife (for cutting roof rack rubber
• Peg Bag
• 2 x Quick Release straps
ERV STAND EASY AWNING
Contents
& Tools Required
AWNING.
not used**
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SUPA PEG ERV
Summary of Contents for SUPA PEG ERV
- Page 1 SUPA PEG A U S T R A L I A ERV STAND EASY AWNING Awning Setup/ Fold Away Instructions Thank you for your purchase of the Australian made and designed ERV STAND EASY AWNING. Please follow these few simple step by step instructions to make setting up your ERV STAND EASY AWNING simple to use and to improve the life span of the product **Please note: two people maybe required to set up and pack away in winds over 5 knots or for unexpected wind gusts if the supply tie down straps are not used** Contents & Tools Required • Mounting Bracket Set (2 Brackets) ) - 13mm Spanner • 4 x 225mm Galv Tent Pegs Pegs - Stainley knife (for cutting roof rack rubber • Peg Bag • 2 x Quick Release straps...
