REV.2014.9.16
500/550 SERIES
A
V
S
S
DVANCED
EHICLE
ECURITY
YSTEM
TM
INSTALLATION GUIDE
www.ultrastarters.com
FCC ID NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2.This device must accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user's authority to operate
this devise.
Advertisement
Table of Contents
Summary of Contents for Ultra Auto Tech Ultra Start 500 Series
- Page 1 REV.2014.9.16 500/550 SERIES DVANCED EHICLE ECURITY YSTEM INSTALLATION GUIDE www.ultrastarters.com FCC ID NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user’s authority to operate this devise.
-
Page 2: Table Of Contents
U500/U550 PAGE 2 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 TABLE OF CONTENTS Wire Diagram..............Page 3 Program Mode...............Page 4 Enter Program Mode System Reset Programing Chart............Page 5 Program Menu 1 Program Menu 2 System Wiring..............Page 6-8 Wire Description Shock Sensor Input Antenna Valet/Programming Switch Data Port Transmitter Programming..........Page 9... -
Page 3: Wire Diagram
PAGE 3 U500/U550 WIRE DIAGRAM INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 EXTERNAL STARTER INTERRUPT CONNECTOR (OPTIONAL) Optional LED port Optional Communication Port LED / VALET Switch RF Antenna Status LED Pin 3 - Blue - Negative Unlock Output (-250mA) Pin 2 - Output for Voltage Inverter Only Pin 1 - Green - Negative Lock Output (-250mA) Pin 4 - Red - 12volt Output for Sensor... -
Page 4: Program Mode
U500/U550 PAGE 4 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 PROGRAM MODE ENTERING PROGRAM MODE 1 - Cycle the Ignition Key On/Off On/Off On. (Leave the key in the ON position) 2 - Press and release the Program Switch 1 time. (*The Siren will chirp to confirm that the system has entered Program Mode.) *If the siren does not chirp repeat steps 1 &... -
Page 5: Programing Chart
PAGE 5 U500/U550 PROGRAM MODE INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 PROGRAM MODE 1 SETTING # SETTING OPTION 1 OPTION 2 OPTION 3 LED FLASHES DESCRIPTION 1 CHIRP 2 CHIRPS 3 CHIRPS IGNITION IGNITION AUTO-LOCK & IGNITION AUTO-LOCK IGNITION AUTO-LOCK AUTO-LOCK UNLOCK ENABLED ONLY... -
Page 6: System Wiring
U500/U550 PAGE 6 INSTALL MANUAL SYSTEM WIRING SYSTEM PROGRAMMING - Menu 1 WIRE DESCRIPTION Pin 3- Blue Wire- Negative Unlock Output (-250ma Output) Pin 2- 12volt Output for Voltage Inverter. Pin 1- Green Wire- Negative Lock Output (-250ma Output) Pin 9- White/Green Wire- 2nd Unlock/ (-) When Disarmed Output Pin 8- Blue Wire- Hood/ Trunk Switch Input (-) Pin 7- Green Wire- Negative Door Pin Input (-) Pin 6- Violet Wire- Positive Door Pin Input (+) - Page 7 PAGE 7 U500/U550 SYSTEM WIRING INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 WIRE DESCRIPTION (-) Output When Unlock Is Pressed For 1 Second. (Programmable) Blue (+) LOW CURRENT OUTPUT FOR VOLTAGE INVERTER ONLY. (-) Output When Lock Is Pressed For One Second. (Programmable) Green (-) 2nd Unlock Output / Ground Output When Disarmed.
-
Page 8: Shock Sensor Input
U500/U550 PAGE 8 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM WIRING SHOCK SENSOR INPUT The supplied dual stage shock sensor connects directly to the shock sensor connector on the alarm module. The adjustment screw on the sensor will increase or decrease the sensitivity. The first and second stage are controlled by the same adjustment screw. -
Page 9: Transmitter Programming
PAGE 9 U500/U550 TRANSMITTER PROGRAMMING INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 PROGRAMMING TRANSMITTERS The system can learn up to 3 different remotes. Each remote to be used MUST be programmed together during the same sequence. For security, when a new remote is programmed all previous remotes are deleted. -
Page 10: System Operation: 2 Way
U500/U550 PAGE 10 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM OPERATIONS (2 WAY) BUTTON BUTTON CHIRP/ SYSTEM FUNCTION ICON DURATION FLASH 1 SECOND ARM ALARM / LOCK DOORS 3 SECONDS ACTIVATE PANIC MODE 1 SECOND DISARM ALARM / UNLOCK DOORS DRIVER’S DOOR PRIORITY 1 SECOND - 1 SECOND (OPTIONAL / PROGRAMMABLE) - Page 11 PAGE 11 U500/U550 SYSTEM OPERATIONS (2 WAY) INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 BUTTON BUTTON CHIRP/ SYSTEM FUNCTION ICON DURATION FLASH CAR FINDER (DEFAULT) PRESS TOGETHER FOR 3 SECONDS AUX 2 (DEALER OPTION)** PRESS TOGETHER AUX 3 OUTPUT** FOR 3 SECONDS (DEALER OPTION) PRESS TOGETHER ENTER CLOCK ADJUST MODE...
-
Page 12: System Operations: 1 Way
U500/U550 PAGE 12 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM OPERATIONS (1 WAY) CHIRP / BUTTON BUTTON PRESS SYSTEM FUNCTION FLASH 1 SECOND LOCK / ARM ALARM 3 SECONDS ACTIVATE PANIC PRESS THEN ACTIVATE CONSTANT LOCK RELEASE THEN OUTPUT ** LOCK PRESS &... - Page 13 PAGE 13 U500/U550 SYSTEM OPERATIONS (1 WAY) INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 ARMS / LOCKS AND TURNS OFF PRESS AND RELEASE SHOCK SENSOR LOCK THEN PRESS AND RELEASE TRUNK (FOR 1 ARM CYCLE ONLY) PRESS TOGETHER AUX 3 OUTPUT** FOR 3 SECONDS (DEALER OPTION) SECOND CAR OPERATION/ PADLOCK.
-
Page 14: Anti Carjack Mode
U500/U550 PAGE 14 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 ANTI CARJACK MODE ACTIVATING ANTI CARJACK MODE (International Model Only) This feature requires that the user must be fully aware of the operation of this feature. If the system goes into full alarm the remote will no longer function until the Anti Carjack Feature is disabled. -
Page 15: Diagnostics
PAGE 15 U500/U550 DIAGNOSTICS INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 ALARM STATUS / DIAGNOSTICS If the alarm system is triggered, the system will retain in memory the cause of the trigger. When disarming the alarm, the siren/horn will chirp 3 times to indicate the alarm had been triggered. -
Page 16: Contact Information
technical support: support@ultrastarters.com additional product information: www.ultrastarters.com IMPORTANT NOTES LOCK, UNLOCK, DRIVER'S DOOR PRIORITY UNLOCK, TRUNK RELEASE AND THE AUXILIARY OUTPUTS ARE OPTIONAL OUTPUTS. ENABLING THESE FEATURES REQUIRES CUSTOM INSTALLATION & PROGRAMMING. THESE FEATURES MAY NOT BE COMPATIBLE WITH SOME VEHICLES. FOR SAFETY REASONS THE TRUNK RELEASE OUTPUT WILL NOT ACTIVATE WHEN THE IGNITION IS IN THE ON POSITION.
