Fitting Instructions
Please read these instructions and terms and conditions carefully
prior to installation. Failure to do so may invalidate the warranty.
Drawings
L
L'
Y
H
mm
mm
mm
mm
500
456
448
759
600
556
548
964
-
-
-
1374 1148
= Bracket position
Pipe Centres
Pipe centres left to right
=
Pipe centres from wall
=
Depth from wall
=
1. Unpack & Inspect
This product should have reached you in perfect condition. Please carefully unpack and inspect this radiator
and all fittings. Your point of purchase must be notified of any shortages or damage within 28 days of
delivery. For further information please see terms and conditions on reverse.
www.supplies4heat.co.uk
WINSLR1.3
Ladder Rail
X
mm
533
738
width minus 44 mm
55 mm - 65 mm
72 mm - 82 mm
