LIP‑3ECTC, LIP‑1ECTC, LIP‑33ECTC
CEA‑709/ IP Router
Installation instructions
Instructions de montage
Montageanweisung
Montagevoorschrift
50º C
max
0º C
min
kg
0.260kg
RH
10 - 90 %
mm
[inch]
24VAC/DC
Instruzioni di montaggio
Instrucciones de montaje
Monteringsanvisning
Made in Austria
LOYTEC
www.loytec.com
Ethernet 2
PWR
107
112
USB
FT
RS-485
FT
RS-485
[4.213]
[4.409]
Advertisement
Summary of Contents for DELTA GROUP LOYTEC LIP‑3ECTC
- Page 1 LIP‑3ECTC, LIP‑1ECTC, LIP‑33ECTC CEA‑709/ IP Router Installation instructions Instructions de montage Instruzioni di montaggio Montageanweisung Instrucciones de montaje Montagevoorschrift Monteringsanvisning 50º C 0º C 10 - 90 % [inch] 0.260kg RS-485 Made in Austria LOYTEC www.loytec.com Ethernet 2 RS-485 24VAC/DC [4.213] [4.409]...
- Page 2 Made in Austria LOYTEC LIP-33ECTC L-IP www.loytec.com EIA709/IP router Ethernet 2 USB 2 Ethernet 1 24VAC/DC USB 1 Connectors POWER 1 Power supply input GND 2 Power supply input PLUS Connectors LIP-3ECTC TP/FT-10 3 not connected (NC) CEA-709 4 Input B 5 Input A Connectors LIP-1ECTC TP/XF-1250 3 not connected (NC)
- Page 3 Made in Austria LOYTEC LIP-33ECTC L-IP www.loytec.com EIA709/IP router DISPLAY Ethernet 2 USB 2 Ethernet 1 24VAC/DC USB 1 Status LEDs GREEN flashing fast Traffic on CEA-709 port TP-1250 GREEN flashing 1 Hz Not commissioned RED permanent CEA-709 port damaged RED flashing fast CEA-709 traffic overload Please update the firmware of the device first,...
- Page 4 35 mm x 7.5 mm DIN rail (EN 50022, BS 5584, DIN 46277-3) LOYTEC electronics GmbH Date Code LIP-33ECTC W27/2015 Serial number of the device MADE IN AUSTRIA SER# 029501-000AB04CF95 Document 88070502 Web edition 06/2015 Printed in Austria http://www.loytec.com Data is subject to change support@loytec.com...
