TRIO Compact Gas Barbecue
D A N G E R
If you smell Gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
W A R N I N G
1. Do not store or use gasoline or other
flammable vapours and liquids in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
---Do not move the appliance during use;
---Turn off the gas supply at the gas container after use;
---Any modification of the appliance may be dangerous
---Read the instruction before using the appliance
---Warning: accessible parts may be very hot. Keep young children away.
G 4 3 0 1 7
Failure to follow all of the Manufacturer' s
instructions could result in hazardous
fires, explosions, property damage, or
serious personal injury or even death.
Follow all leak check procedures carefully
prior to operation of barbecue, even if
grill was dealer assembled. Do not try to
light this barbecue without reading the
Lighting Instructions section of this manual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
W A R N I N G
W A R N I N G

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRIO Compact and is the answer not in the manual?

Questions and answers

Summary of Contents for FUTUR TRIO Compact

  • Page 1 TRIO Compact Gas Barbecue G 4 3 0 1 7 D A N G E R W A R N I N G If you smell Gas Failure to follow all of the Manufacturer’ s 1. Shut off gas to the appliance.
  • Page 2 Gas type :Butane/ Propane Gas Category :I3B/P(30) Gas pressure :28~30 mbar 0598 Effect input grill for G43017 :11.3 kW Consumption for G43017: 825g/h Destination country: NO FIN SE This appliance has been made with regard to the European Gas Standard EN498 and EN484 and bears the CE certification No.
  • Page 4 I N S T A L L A T I O N After purchasing your gas cylinder hose and regulator, you will be ready to set it up with your Barbecue. Position the gas cylinder at the side of your barbecue, not underneath, keep in mind that the cylinder must be keep away from heat and in the safe position.
  • Page 9: Cleaning Instructions

    Cleaning instructions 1. Turn the burner on for 15-20 minutes.Grease drippings will be burned off from your grill as well as your appliance is cold before continuing. 2. Grids should be cleaned periodically by soaking and washing in soapy water. 3.
  • Page 10 of gas...
  • Page 11 Item No. Description Part No. Quantity 1/4"-20UNC X38 Screw 20120-13038-036 1/4"-20UNC Nut 31220-13000-036 wheel spacer G305-0024-9088 ø8 Flat Washer 40300-08000-036 hinge pin G306-0005-9088 NO.10-24UNCX10 Screw 20124-10010-036 ø5 Lock Washer 41400-05000-206 ø5 Flat Washer 40300-05000-036 1/4"-20UNC X18 Screw 20120-13018-036 ø7 Lock Washer 41400-07000-206 Fibre Washer G431-0018-9000...
  • Page 12 G43017 Part List Item No. Quantity Description Part No. Item No. Quantity Description Part No. Top Lid G430-0098-9000 Shelf mount(R),Rear C423-0014-9031 Thermometer G401-0005-9100 Thermometer Bezel G404-0034-9000 Manual G430-M017-01 Handle G433-0018-9100 Hardware pack G430-B017-01 Lid bumper Rubber G303-0038-9000 Firebox Weldment G430-B100-9001 Warming Rack G430-0003-9081 Fry Set...
  • Page 13 G43017 Explode Diagram Manual Hardware Pack...
  • Page 14: You Will Need

    Attach bottom shelf to right leg and left leg by using hardware #1 and #2. YOU WILL NEED: Insert wheel axle rod into wheels.Cart legs, and the other wheel by using hardware #3 (x2) and #4 (x1) and #5 (x1). YOU WILL NEED: Attach the frotn panel to both cart legs.
  • Page 15 Carefully place the fire box onto cart. Connect firebox to both sides of cart leg as shown by using hardware #2 (x4), #9 (x4), #10 (x4) and #11 (x4.) YOU WILL NEED: Assemble 2 side shelf brackets to the side shelf by using hardware #12 (x4) and #8 (x4).
  • Page 16 Open lid and position the three flame tamers above the burner as shown. Places the cooking grate and griddle above the flame tamers. Insert ends of warming rack pivot wire into holes inside of grill lid, insert ends of warming rack leg wire into holes insides of firebox.
  • Page 17 Unscrew the igniter cap and place AA battery with positive end (+) facing outward. Screw igniter cap onto igniter as shown.
