  • Page 1 Glencoe® SF4600 SOIL FINISHER® UM4650 UNIMULCH® TILLAGE TOOLS OPERATOR’S MANUAL Form number 1PD7611197 November, 1997...
  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION DEALER/CUSTOMER INFORMATION: ..... 2 SAFETY SAFETY PRECAUTIONS ......3 SAFETY DECALS .
  • Page 4 NOTES...
  • Page 5: Introduction

    INTRODUCTION The Glencoe® SF4600 Soil Finisher® is a seedbed preparation tillage tool. It is designed for secondary tillage in previously tilled soil such as plowed or coulter chiseled ground. This machine features either G-tine shanks or spring cushion 165 pound point pressure shanks. The Glencoe®...
  • Page 6: Dealer/Customer Information

    DEALER/CUSTOMER INFORMATION TO THE DEALER: TO THE CUSTOMER: Warranty Registration Warranty Registration A warranty registration form must be completed for Be sure to sign the registration form and keep your each serial-numbered unit by the dealer and signed copy. by both the dealer and the customer before or upon Know Your Equipment delivery.
  • Page 7: Safety Precautions

    If there is any portion of this manual or of the machine’s operation you do not understand, contact your local authorized Glencoe® dealer, or AGCO® Corporation. • Always shut off tractor, shift to “Park” position (or shift to neutral), set brakes and cycle hydraulic levers before dismounting tractor or working around the machine.
  • Page 8 • Openings in the skin and minor cuts are • Never transport machine unless hydraulic susceptible to infection from hydraulic fluid. If systems are completely charged with hydraulic injured by escaping fluid, see a doctor at once. oil and the transport locks are engaged. Without immediate medical treatment, serious •...
  • Page 9: Safety Decals

    SAFETY DECALS DECALS The following decals are installed to alert operators to hazards in specific machine areas. The decals are for personal safety... READ AND UNDERSTAND THE DECALS! • Keep decals clean by wiping off regularly. Use a cleaning solution if necessary. •...
  • Page 10 SAFETY DECALS...
  • Page 11: Operation

    OPERATION Warning! Do not unhitch from tractor while in the raised position. Unhitching the machine in a raised position could cause the front of the machine and the hitch to spring upward possibly injuring the operator and bystanders. Always store the machine in the lowered position (shovels resting on the ground).
  • Page 12 OPERATION ATTACHING THE IMPLEMENT Warning! Be sure no one is between the tractor and the implement while the tractor is being positioned during the hitching operation. • Carefully back your tractor into place and attach the clevis to the drawbar. Use the correct size drawpin for the clevis.
  • Page 13 OPERATION GENERAL OPERATION INFORMATION • Before raising or lowering the machine or operating the wing fold mechanism be certain the hydraulic system is charged with hydraulic oil. (Refer to the “Charging the Hydraulic System” section of this manual. • Check the hydraulic oil level of the tractor. Add oil as required.
  • Page 14: Field Operation

    OPERATION FIELD OPERATION Warning! Avoid sharp turns using brakes. Drive Warning! Never allow anyone to ride on this slowly over rough ground, side hills equipment. Clear the area of and around curves to avoid tipping. bystanders before starting operation. Preparation for field use. Move the tractor hydraulic levers which control both the axle cylinders and the winglift cylinders rearward as if to raise both the unit and the wings to help...
  • Page 15 OPERATION Initial Main Frame and Wing Frame Leveling Main frame turnbuckle adjustments should be made simultaneously so that the main frame is level across the width of the machine. Then level the wings to the main frame. Remove the wrench provided from the storage position (B).
  • Page 16 OPERATION Frame Leveling After achieving the proper depth, Recheck the level of the machine (front to rear). Adjust the hitch turnbuckle (C), if necessary. Once set, the machine will remain level as long as the drawbar height remains the same. Recheck shank depth. GNC0012A Maintaining Uniform Depth The raising shafts are synchronized for raising and...
  • Page 17 OPERATION Shanks Three edge-formed shank options are available: G-Tine: Available on all size models of SF4600. GNC0005 Spring cushion 165# point pressure shank: Available on all size models of SF4600. GNC0021 Auto-reset 550# trip shank: Available on all size models of UM4650. (18’ thru 341/2’) GNC0007 Ground Tools 11"...
  • Page 18 OPERATION Spring Cushioned Disc Gangs The disc gangs should not operate deeper than 3" to 4" and no deeper than necessary for desired residue cutting. In high residue conditions the discs should only cut the residue. In coulter chiseled ground the discs should be adjusted to run just above the bottom of the furrows between the ridges.
  • Page 19: Field Operation Optional Attachments

    OPERATION FIELD OPERATION OPTIONAL ATTACHMENTS Treader Gangs The teeth on the treader gangs are curved. The treader will function properly only if the treader gangs are rotating in the correct direction in relationship to the direction of pull.
  • Page 20 OPERATION Treader Gangs The treader gangs can be set to run at various angles ( 0, 5, 10, 15, 20 degrees). As the angle increases so does the aggressiveness of the treader. In wet conditions, reduce the angle to reduce plugging. •...
  • Page 21 OPERATION Rolling Reels The rolling reels main function is to level the soil and break clods. The reels will bring clods and residue to the surface. Rolling reel depth should not exceed 3" - 4". Do not operate deeper than the shanks. Depth of operation is adjusted by changing the downward force of the reels.
  • Page 22 OPERATION 5 Bar and 8 Bar Spike Tooth Harrows The tooth angle is preset and cannot be changed. However, the front bar angle can be changed by reversing the tow lugs (C). Harrow adjustments are made by adjusting the length of the tow chains (A). For maximum leveling and clod breaking, adjust the tow chains to allow the entire harrow to pull level with the ground.
  • Page 23: Transport & Storage

    TRANSPORT & STORAGE TRANSPORT • Turn on flashing warning lights before driving on public roads, except when prohibited by law. Warning! Comply with your state and local laws governing highway safety, lighting & • Make sure reflectors are visible when transporting.
  • Page 24: Storage

    TRANSPORT & STORAGE SVM Emblem Always have the SMV emblem clean and in full view of a vehicle approaching from the rear. The SMV (Slow Moving Vehicle) emblem must be on the implement if it is to be transported on public roadways.
  • Page 25: Lubrication

    LUBRICATION LUBRICATION Warning! Do not clean, adjust or service when machine is in motion. Warning! All hydraulically or mechanically elevated components must be blocked to prevent accidental lowering or must be lowered to the ground when adjustments or repairs are made. Lubrication Daily Annually...
  • Page 26: Maintenance & Service

    MAINTENANCE & SERVICE MAINTENANCE Warning! Do not clean, adjust or service when machine is in motion. • All hydraulically or mechanically elevated components must be blocked to prevent accidental lowering or must be lowered to the ground when adjustments or repairs are made. •...
  • Page 27 NOTES...
  • Page 28: Hydraulics - Charging The Hydraulic System

    HYDRAULICS - CHARGING THE HYDRAULIC SYSTEM HYDRAULICS Warning! Be certain the hydraulic system is fully charged with oil before use. Air in the hydraulic system can result in uncontrolled movement of the wings during raising and lowering operations Warning! Lower the machine to the ground, shut off hydraulic supply and relieve all hydraulic pressure before disconnecting hydraulic lines.
  • Page 29 HYDRAULICS - CHARGING THE HYDRAULIC SYSTEM Purging Rephasing Series (Slave) System Each of these series cylinders are equipped with a bypass port located at the rod end of the cylinder. This port allows air to be purged from the system thus rephasing the cylinder.
  • Page 30 HYDRAULICS - CHARGING THE HYDRAULIC SYSTEM Charging the Hydraulic System Prior to using or transporting the implement for the first time it is necessary to charge the hydraulic lines and cylinders with approximately 2 to 5 gallons of hydraulic oil. Charging a new unit which has not been Recharging the hydraulic system of a previously charged with hydraulic oil.
  • Page 31: Hydraulics

    HYDRAULICS TIGHTENING STRAIGHT THREAD FITTINGS The straight thread hydraulic fittings require precise tightening. Over-tightening of the hydraulic fittings will ruin the sealing surfaces and will require the replacement of the damaged parts. Do not use any teflon tape or thread sealant on any JIC fittings or in o-ring port cylinders. Proper initial tightening procedure depends on the mating parts being connected.
  • Page 32: Torque Chart

    TORQUE CHART BOLT TORQUE CHART - COARSE THREAD Do not replace bolts with a grade other than the grade specified. GRADE 1 GRADE 2 GRADE 5 GRADE 8 Metric Torque Ft-Lbs for - Rd Hd Sq No Marks 3 Lines on 6 Lines on Size Grade...
  • Page 33: Specifications

    SPECIFICATIONS GLENCOE® SF4600 SOIL FINISHER® MODEL TYPE NUMBER NUMBER EST. TRANS. TRANS. APPROX. DRAWBAR WIDTH HEIGHT WEIGHT FOLD SHANKS DISCS HORSE- w/o REAR POWER ATTACH 18’ Flat 108-144 13’ 8’2” 8,700 21’ Flat 126-168 13’ 8’2” 9,000 25’-6” Over 90 153-204 16’...
  • Page 36 GLENCOE AGCO CORPORATION 4205 River Green Parkway Duluth, Georgia 30096 Printed in U.S.A.
