SupeFun_instructions_8.5x11_FINAL.pdf
PARTS LIST
ALL MODELS
4 - Legs
4 - Frame Bars
1 - Jumping Mat
1 - Safety Pad
1 - Safety Plaque w/ 2 Ties
1 - Instruction Manual
1 - Backyard Trampolining Book
1 - Warranty Card
Set-up Instructions - PLEASE READ CAREFULLY BEFORE SET UP!
NOTE: Before you begin, remove the shrink wrap from the end of each "round" frame bar. There is
a small insert that is used to protect the bar during shipping. Remove this insert and discard.
1
Lay 4 frame bars in a complete circle on a
level surface with the spring slots facing up.
Place the 4 leg bars inside the circle with the
leg ends near the leg insert sleeves on the
frame bars. Note: Make sure there is one
frame bar joint centered to each leg.
3
Place the trampoline jumping mat on the
ground, inside the frame. Take one spring
and hook any one triangle on the jumping
mat. Hook the opposite end of the spring
into the spring slot on the frame bar.
1
9/4/15
5:57 PM
ROUND TRAMPOLINE
ROUND TRAMPOLINE
ROUND TRAMPOLINE
ROUND TRAMPOLINE
SET-UP INSTRUCTIONS
SET-UP INSTRUCTIONS
SET-UP INSTRUCTIONS
SET-UP INSTRUCTIONS

SPRINGS PER MODEL

14' Super Bounce - 100 Springs
16' Mega Bounce - 108 Springs
XL Big Air - 124 Springs
(includes 2 extra springs)
2
Lift 1 frame bar and slide a leg end into the
leg insert sleeve on the frame bar. Repeat
step for all 4 legs. Join the frame bars
together to close the circle.
IMPORTANT!!
When pulling the spring, grab the spring at
the end going into the hole in the frame. As
shown above, avoid holding the spring in the
red area as this will damage the spring.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 14' Super Bounce and is the answer not in the manual?

Questions and answers

Summary of Contents for SUPERFUN 14' Super Bounce

  • Page 1 SET-UP INSTRUCTIONS SET-UP INSTRUCTIONS PARTS LIST ALL MODELS SPRINGS PER MODEL 14' Super Bounce - 100 Springs 4 - Legs 4 - Frame Bars 16' Mega Bounce - 108 Springs 1 - Jumping Mat XL Big Air - 124 Springs...
  • Page 2 SupeFun_instructions_8.5x11_FINAL.pdf 9/4/15 5:57 PM ROUND TRAMPOLINE ROUND TRAMPOLINE SET-UP INSTRUCTIONS SET-UP INSTRUCTIONS Working around the trampoline, attach a Add a second spring next to springs that spring on every tenth triangle and stretch where attached on Step 4. Repeat this the spring to the corresponding spring slot process until all the springs are attached.
