Q u i c k S t a r t G u i d e
Quick installation guide
Suzhou Optimal Machinery Co.,Ltd.
Address: No. 75,Jiangpu Road,Suzhou Industrial Park,Suzhou City,China
In order to safely use the product,please carefully read the operation instruction manual.
Tel: +86-15851682580
Fax: 0512-62760380
Web:www.optfan.net
Email:ericleung@optfan.com
Suzhou Optimal Machinery Co.,Ltd.
Advertisement
Table of Contents
Summary of Contents for Suzhou Optimal Machinery OPTFAN
- Page 1 Q u i c k S t a r t G u i d e Quick installation guide Suzhou Optimal Machinery Co.,Ltd. Address: No. 75,Jiangpu Road,Suzhou Industrial Park,Suzhou City,China In order to safely use the product,please carefully read the operation instruction manual.
-
Page 2: Table Of Contents
Contents Safety&Precautions..........1 Product Introduction. -
Page 3: Safety&Precautions
1.Product introduction SAFETY & PRECAUTIONS NAVIGATOR Series The third generation BLDC HVLS(BLDC High Volume-Low Speed) large energy-saving ceiling READ THE ENTIRE MANUAL BEFORE OPERATING THE FAN fan named by OPTFANS is an application based on permanent-magnet brushless tech, acme industry design and intelligent control tech. The fans can circulate the airlfow in the space efficiently, then improve the comfortable feeling greatly. -
Page 4: Packing List
2.Packing list Motor case Blade case Motorx1 Upper York Clamp I Type Connect Winglets Button plug Wood screw Cable protection Plastic Safety Wire U-Joint U-Joint Base Off the wall code Plastic wall Wiring cap hosex2 expansion tube Aluminum bolts m4*5 bolts m4*10 bolts m5*16 bolts m8*18... -
Page 5: Product Drawing
3.Product drawing H-type steel structure plug-in Steel wire Clamp plate L-type adapting pieces Extension tube Fan blade Turnbuckle and clamps Fan blade tail BLDC motor... -
Page 6: Standard Part Structure Diagram
3.1 Standard part structure diagram 4. Preparation before installation 4.1 Security tool preparation Steel structure fastening Main body structure fasteners stator shaft H-beam upper dust cover clamp plate rotor safety cap work gloves safety belt warning line bottom cover Upper York 4.2 Installation tool preparation level-meter speed wrench... -
Page 7: Installation Condition And Types
Hang on Concrete Side Mount on Concrete 5. Installation conditions and types 5.1 Roof installation requirement Roof extension tube 0.3-5M safety diatance ≥0.2M drive parts safety distance Confirm the size of the concrte beam, 0.3M ≥0.2M and the position to mount bracket and Assemble extended top plate with guarantee to keep the distance from the bending pieces, to fit the concrete beam. -
Page 8: Fan Installation Procedures
Extension rod threading 6.Fan installation procedures put cable through the extension tube, leave 30cm outside to connect cables from motor. Site survey confirmation Confirm installation position PS:put cable in cable pipe then Measure the height to mount fan with cable through extension tube. - Page 9 Install safety rope Installation of steel wire fastener Put wire through a small hole on extension tube, and then twist the whole beam, Please pre-judge the 4 points can bear the force or not, put the wire through the adjust the safety wire and tighten the guy wire locks with speed wrench(f) and 10# hole punched beforehand on the purlin.Connect turnbuckle with eyebolt on motor socket wrench(r).
-
Page 10: Control Panel And Display System
Installation control system 7. The control panel and display system Fix control box to confirm mounted position,keep box balanced.Punch hole with electric tools and fix buckles into the holes with cross screwdriver(I).The box should be fixed at a height between 1.2m-1.3m from the ground. control cabinet switch power output... -
Page 11: Troubleshooting
Non-professional staffs do not open the electrical control box! For repair or adjustment, Suzhou Optimal Machinery Co.,Ltd will send you our trained professionals or engineers; If you find the equipment is damaged or has abnormal sound, please stop running as soon as possible, cut off power supply, and contact our service department;... -
Page 12: Specification Of Parameters For Control System
Drive Mode STOP Output Current Display Monitors the output current of the drive. FOUT STOP Output Voltage Reference 10. Specification of parameters for control system Monitors the output voltage of the drive. FOUT Drive Mode STOP Monitor Display Status Display Monitor parameters (U parameters) are displayed. -
Page 13: Customer Service
Brake transistor is short-circuited,thus the brake function is Brake chopper short-circuited disconnected. Brake check Brake resistor is not connected/working. 1、Login in our website:www.optfan.net,browse to download the latest product technical Power board over temp Heat sink cut-out temperature has been reached. specification. Motor phase U missing Motor phase U is missing. -
Page 14: Fault Displays,Causes And Possible Solutions
LED Operator Display Fault Name 13.Fault Displays, Causes and Possible Solutions Input Phase Loss Drive input power has an open phase or has a large imbalance of voltage between phases. Detected when L8-05 = 1 (enabled). Cause Possible Solution Detailed Fault Displays, Causes and Possible Solutions •... -
Page 15: Quality Assurance
14.Quality assurance Maintenance cycle Details of the warranty of quality 9 steps 18 steps safety Replacement of Replacement of Replacement of Replacement of Time deep-clean inspections safety Mechanical Safety radiator fans in Inverter Quality assurance is for the whole machine .The quality guarantee period is from the date of (whole fan) fastening system Balanced Cable... - Page 16 STOP Verify Function Lists all parameters that have been edited or changed from default settings. Inspection Items:(Customer selection) STOP Acceptance report of installation and commissioning Setup Programming A select list of parameters necessary to get the drive operational quickly. Mode Yes □...
