Instructions-Parts 2.5 Gallon 313291D Pressure Tank (Non-ASME Design) For low-pressure painting and coating applications requiring portability, small batches, or frequent color changes 50 psi (350 kPa, 3.5 bar) Maximum Working Pressure Model 24A555, Series A (shown) Basic portable pressure tank Model 24A557, Series A with dual regulators Important Instructions...
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
Installation WARNING WARNING WARNING WARNING PRESSURIZED ALUMINUM PARTS HAZARD Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or fluids containing such solvents in pressurized aluminum equipment. Such use can cause serious chemical reaction and equipment rupture, and result in death, serious injury, and property damage. PERSONAL PROTECTIVE EQUIPMENT You must wear appropriate protective equipment when operating, servicing, or when in the operating area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic...
Installation Setup 7. Connect an air supply hose to the 1/4 npt air inlet fit- ting (9c-1). Connect the gun’s air atomizing hose to fitting (9c-2). See F . 3 for single-regulated tanks. • Single-Regulated Tank (Model 24A555): When See F .
Operation Operation Pressure Relief Procedure Pressure tanks remain pressurized until pressure is manually relieved. 1. Shut off the air supply to the tank. 2. Lift the pressure relief valve ring (1b) to open it. See . 5. 3. When no air is escaping through the valve, unscrew the wing nuts and remove the tank cover (H).
Cleaning and Maintenance Cleaning and Maintenance 1. Follow the Pressure Relief Procedure, page 6. 8. Remove the spray gun air cap. 2. Unscrew the wing nuts and remove the cover (H). 9. Turn on the air supply. Trigger the gun into a waste container until clean solvent comes from the gun.
Parts Parts Model 24A555, Pressure Tank with Single Regulator not visible ti12990a ti12990a ti12986a Ref. Ref. Part No. Description Qty. Part No. Description Qty. U10004 REGULATOR ASSEMBLY, includes ----- BARE PRESSURE TANK, includes items 9a-9d) items 1a-1c 8220 GAUGE, air pressure, 0–100 psi TANK LINER, low density polyethyl- (0 to 700 kPa, 0–7 bar) ene (not shown)
Page 9
Parts Model 24A557, Pressure Tank with Dual Regulators not visible ti12992a ti12988a Part No/Description Ref. Ref. Part No. Description Qty. Part No. Description Qty. U10004 REGULATOR ASSEMBLY, includes ----- BARE PRESSURE TANK, includes items 9a-9d) items 1a-1c 8220 GAUGE, air pressure, 0–100 psi TANK LINER, low density polyethyl- (0-700 kPa, 0–7 bar) ene (not shown)
