Summary of Contents for Seiki Vista Plus Screen
- Page 1 Installation Manual for Vista PLUS SCREEN For right hinged doors Durable. Reliable. Attractive. For door openings up to 36” wide (914 mm) and 81 ” high (2,064 mm) Quick Easy Size Install PX11-0601R...
- Page 2 The Vista Plus Screen was designed for easy sizing and installation. This Installation Manual provides a step by step guide through the entire process. We also recommend visiting the Seiki Website at www.seikiscreensystems.com/na...
-
Page 3: Table Of Contents
..............13 For installations on double doors (French doors), one left Vista Plus Screen and one right Vista Plus Screen and one Double Door Link Kit will be required. Please refer to the Installation Manual within the “Double Door Link Kit” prior to installation. -
Page 4: Getting To Know The Vista Plus Screen
Spring Tension the Door Opening? Adjuster Sliding Bar Retracting Make sure the Vista Plus Screen will fit the door. The Bottom Cap Mesh Guide Vista Plus Screen will accommodate a door Is the Door Opening Square? opening of up to 36” (914 mm) wide and 81 1/4”... -
Page 5: Parts And Tool List
Parts and Tool list Before beginning, make sure that Stickers, 2pcs. for Latch all these parts are included in 5/8” (16 mm) Pan Head Screws, 10pcs. for Mounting Bracket the Vista Plus and Catch Frame Screen package. 1-1/4” (32 mm) Wood Screws, 3pcs. -
Page 6: Measuring The Door Opening
Vista Plus Screen will be installed. Seiki recommends positioning the Vista Plus Screen flush with the outside edge of the door frame (the furthest point away from the door.) Measure from the top of the door frame to the door sill at a point 1 5/8”... -
Page 7: Sizing The Vista Plus Screen
Vista Plus Screen Sizing the If the door opening is smaller than 36” (914 mm) wide and 81 1/4” (2,064 mm) high, the Vista Plus Screen must be cut. Determining Length to be Cut from Top and Bottom Rails To determine the length to be cut from the Top and Bottom Rails, use the following formula:... -
Page 8: Cutting The Top/Bottom Rail And Catch Frame
NOTE: It is important to wear safety glasses at all times when cutting components of the Vista Plus Screen. After cutting any part of the Vista Plus Screen, use a file to remove any burrs from the cut surfaces. -
Page 9: Cutting The Screen Housing
Housing Assembly Cutting the Screen It is easy to cut right through the Screen Housing Assembly of the Vista Plus Screen using a chop saw or hacksaw. Sliding Bar NOTE: All cutting will be done on the upper end Top Cap of the Screen Housing Assembly. -
Page 10: Installing The Screen Housing
Screen Housing Assembly Securing the Mounting Bracket Mounting Surface The Mounting Bracket of the Vista Plus Screen is installed on the right inside surface of the door frame. The ideal “L” Shaped Edge minimum dimension of this surface is 1 5/8” (42 mm). -
Page 11: Installing The Top Rail
Top Rail Catch Frame Installing the Installing the Top Rail: Remove the backing on the adhesive strip on the Top Rail. Place the uncapped end of the Top Rail over the Sliding Bar Top Cap and slide the Top Rail into the Top Rail Mesh Lock Mesh Lock Adjuster. -
Page 12: I Nstalling The Bottom Rail
Bottom Rail Installing the and adjusting the Catch If the Bottom Rail did not require cutting, it is important to Bottom Rail Type “A” select the correct Bottom Rail for installation. The Vista Plus Screen package comes with two Bottom Rails to Flat Surface accommodate both flat and angled door sills. -
Page 13: Final Steps
Adjustments Final Adjusting the Mesh Mesh Lock Adjuster The Vista Plus Screen can be adjusted to reduce the amount of mesh discharged from the Screen Housing. Dial This keeps the mesh tight to maintain the Vista Plus Screen's effectiveness in keeping out unwanted insects. - Page 14 Do not use oil, grease, or oil based sprays or lubricants on any of the components on the Vista Plus Screen. These products attract dirt and debris, and may cause the Vista Plus Screen to react abnormally.
- Page 15 The Vista Plus Screen was designed for easy sizing and installation. This installation Manual provides a step by step guide through the entire process. If there are any questions during the installation of the Vista Plus Screen, we recommend visiting the Seiki Website at www.seikiscreensystems.com/na .
- Page 16 Limited Lifetime/Non-transferable Manufacturers Warranty The Vista Plus Screen is warranted by Seiki Screen Systems to be free of manufacturers' defects in materials or workmanship, for as long as the original purchaser owns and or resides at that residence and that the product remains at its original point of installation.
