Electrotherm Demister Installation Manual And Product Care

Mirror Demister with Heat Foil Element
Installation Guide and Product Care

INSTALLATION PROCESS

Preparation

Before installing
If there is any grease use a cloth with an alocohol based solution to clean it.

Simple installation

Centre the
the back of the mirror. Use adhesive tape to fix the demister in position as shown.
At the opposite end to the where the adhesive tape has been placed, peel the paper
side facing the back of the mirror and begin to pull it away from the film
As the paper is removed apply pressure to the whole of the outwards facing surface of
the demister to attach it to the back of the mirror.
Completely remove the adhesive tape and the protected paper, pressing strongly
against the film on the back of the mirror in order to avoid air bubbles from forming

Additional Notes

It is recommended the
The electrical connection must comply with regulations.
The film must be protected from scratches resulting from the use of metal objects such as cutters and knives.
If the power cable is damaged, do not change or repair it: the whole
products are exclusively available at UFH Supplies: www.ufhsupplies.co.uk
1
DEMISTER make sure the back of the mirror is totally clean and dry.
DEMISTER with the paper side facing downards towards
DEMISTER is installed at a minimum ambient temperature of 15°C.
DEMISTER must be replaced.
