Summary of Contents for Diamond Vantage TS400
- Page 1 DIAMOND VANTAGE ® TS400 TILE SAW OWNER’S MANUAL Revision 20001 03.2020 Manual Part#: 983020075201 CAUTION: Read all safety and operating instructions before using this equipment. This operator’s manual must accompany the equipment at all times. www.diamondvantage.com...
-
Page 2: Table Of Contents
TS400 TILE SAW OWNER’S MANUAL DIAMOND VANTAGE ® www.diamondvantage.com TABLE OF CONTENTS page GENERAL SAFETY RULES FOR ALL POWER TOOLS SYMBOLS III. TECHNICAL SPECIFICATIONS GETTING TO KNOW YOUR SAW ACCESSORIES/PARTS BLADE INSTALLATION VII. SAFE OPERATING PRACTICES FOR TILE SAW 9-12 VIII. -
Page 3: General Safety Rules For All Power Tools
I. GENERAL SAFETY RULES FOR ALL POWER TOOLS WARNING! READ AND FOLLOW ALL SAFETY, OPERATING AND MAINTENANCE INSTRUCTIONS BEFORE USING THE TOOL. Failure to read and follow these instructions could result in injury or death to you or others as well as damage to the tool and/or reduced equipment life. - Page 4 16. DON’T OVERREACH. Keep proper footing and balance at all times. 17. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for better and safer performance. 18. DISCONNECT TOOL. When not in use, before servicing, or when changing attachments—wheels, bits, cutters, etc—all tools should be disconnected.
-
Page 5: Symbols
Keep dry Well ventilated Remove tools Do not step on Pay extreme attention No non-working personnel Away from all moving parts Do not touch hot parts III. TS400: TECHNICAL SPECIFICATIONS TS400 MOTOR DIRECTION OF MAX. BLADE WEIGHT DIMENSIONS SHAFT ROTATION CAPACITY 10”... -
Page 6: Getting To Know Your Saw
IV. TS400: GETTING TO KNOW YOUR SAW Motor Assembly Blade Guard Assembly Power Switch Splash Guard Diamond Blade Cutting Head Adjustment Handle Vertical Arm Assembly Rail Platform Assembly Main Table Assembly Water Tray • 6 • diamondvantage.com... -
Page 7: Accessories/Parts
V. TS400: ACCESSORIES/PARTS The following are parts included in the package. NAME (Qty.) NAME (Qty.) Miter Block (1) Side Extension Table (1) Part Number Part Number 000101802-AG 475010803I-AG NAME (Qty.) NAME (Qty.) 45º/90º Edge Guide (1) Drain Plug (1) Part Number... -
Page 8: Blade Installation
VI. TS400: BLADE INSTALLATION Unplug the tile saw before installing a blade. WARNING! Carefully raise the cutting head to its highest Place the blade to cut completely through the position and secure it into place by tightening the material. Failing to do so may allow the saw to... -
Page 9: Safe Operating Practices For Tile Saw
VII. TS400: SAFE OPERATING PRACTICES FOR TILE SAW WARNING! WARNING! For your own safety and the safety of others, do The dust generated by cutting of tile, marble, not attempt to operate this saw until you have stone, bricks etc. can be harmful to your health. - Page 10 VII. TS400: SAFE OPERATING PRACTICES FOR TILE SAW IMPORTANT - If there is any tendency for the WARNING! saw to move during certain operations, such as Not dressing the blade frequently or setting when cutting large heavy tiles, the saw must be the blade too high will cause it to grab the tile, securely fastened to a supporting table.
- Page 11 • Do not unplug the cord if the electrical outlet Figure 2(D). If a Ground Fault Circuit Interrupter outlet is gets wet. Disconnect the fuse or circuit breaker not available, Diamond Vantage has it available as an ® that supplies power to the tool. Then unplug and accessory item.
-
Page 12: Using The Cutting Table
VIII. TS400: SAFE OPERATING PRACTICES FOR TILE SAW 21. EXTENSION CORDS • Ground Fault Circuit Interrupter (GFCI) protection • Only use extension cords that are intended for should be provided on the circuit(s) or outlet(s) outdoor use and marked “Acceptable for use with to be used for the tile saw. -
Page 13: Electrical Motor Specification
X. TS400: ELECTRICAL MOTOR SPECIFICATION RECOMMENDATIONS: TS400 Horse Power 2 HP • It is recommended that a minimum 15 amp circuit be used Voltage 115V~120V while operating this saw. This will prevent possible power Amps 15 amps interruption or loss. -
Page 14: Troubleshooting
XI. TS400: TROUBLESHOOTING WARNING! For your safety and the safety of others, turn the power switch off and always remove the plug from the power source before troubleshooting. Repairs performed by unauthorized personnel could cause serious hazard. We recommend that service to this tool be performed by a qualified service technician with original equipment replacement parts. -
Page 15: Cutting Depth
Likewise, it does not apply to any unit which has been subjected to misuse, neglect or accident, nor to any machine which has been repaired or altered by any person other than Diamond Vantage authorized ®... -
Page 16: Replacement Parts List
XIII. TS400: REPLACEMENT PARTS LIST - 1 MAIN ASSEMBLY 18 17 Part Name Part No 1. Rail Platform Assembly 563210802A-AG 2. Table Assembly 675010804R-AG Part Name Part No 3. Vertical Arm Assembly 5631108041B-AG 12. Water Pump 000103053 4. Cutting Head Assembly 33G108102B-AG 13. - Page 17 XIII. TS400: REPLACEMENT PARTS LIST - 2 CUTTING HEAD ASSEMBLY 27 20 Part Name Part No 16. M4 Narrow Washer 381046101 Part Name Part No 17. M4 Spring Washer 3810460041 1. Cutting Head 33G108102B 18. M4 x 0.7 x 20L Cross Screw 3810420202 2.
- Page 18 XIII. TS400: REPLACEMENT PARTS LIST - 3 TABLE ASSEMBLY Part Name Part No Part Name Part No 1. Main Table 675010804F 9. 1/4” - 20 x 1-1/4”L x 3/4” Hex Bolt 382011032 2. Roller Mounting Plate 465722801 10. 1/4”- 20 x 1-1/4”L Flat Head Set Screw 3820180021 3.
- Page 19 XIII. TS400: REPLACEMENT PARTS LIST - 4 BLADE GUARD ASSEMBLY Part Name Part No 1. 10” Blade Guard 373310802W Part Name Part No 2. Splash Guard 483514603 7. 120cm Pipe 000101255 C. M6 x 15L Combination Screws 3810610153 8. 39cm Pipe 000101254 D.
- Page 20 XIII. TS400: REPLACEMENT PARTS LIST - 5 RAIL PLATFORM ASSEMBLY Part Name Part No 1. Rail Platform 563210801A Part Name Part No 2. Front Platform Anchor 465624401A 9. D21 Ring 38122C001I 3. Rear Platform Anchor 465624402A 10. D8 x 90L Quick Release Pin 38108A090K 4.
