ANV APT1-S Manual

APT1-S
WEEKLY PROGRAMMABLE TIMER
MANUAL
Indicating a message , If not complied, May cause a
WARNING
misoperation to cause a person to receive Damage
or property damage.
This product contains battery ! battery may be in danger of
leaking or explosion and causing personal injury.
Do not use the product at temperature of more than 55 degrees
Celsius. Do not contact with liquid.
Battery life depends on the usege.
CAUTION
Do not contact the terminal when the power ON.
This may be caused by an electric shock or personal injury.
terminal cover must be installed after the wiring.
Do not use in places with inflammable and explosive gases.
Tighten the terminal screws to the rated torque.
Please cut off the power of the load or manual output to OFF
and confirm the security of the system before changing the
setting. Otherwise, it may cause damage to the machine.
Serious injury may occasionally occur due to fire or explosion of
a battery, or leakage from a battery. Never attempt to short the
positive and negative terminals, recharge, disassemble, deform
by applying excessive pressure, or expose the battery to fire.

PARTS DESCRIPTION

PROGRAMMABLE TIMER
4
10
12/24H Select
3
CLOCK PROG. DAY HR MIN SEC
1 1
RESET CLEAR MODE On/Auto/Off
Start/Pause
12
9

DISPLAY DESCRIPTION

1
4
5
6
When switch to Auto mode from ON
or OFF, output contact will be kept in the previous mode.
Than, output contact will be controlled by program setting.

DIMENSIONS

48.8
PROGRAMMABLE TIMER
Select
12/24H
CLOCK PROG. DAY HR MIN SEC
RESET CLEAR MODE On/Auto/Off
Start/Pause
ANV ELECTRIC
SYMBOL
1 LCD Display
2 Output Indicator
3 Clock Key
1 4 Week Key
5
5
Hour Key/
6 Minute Key
6
7 Second Key /
7
Manual Output Key /
8
8
Start Key / Pause Key
2 9 Mode Key
10 Program Key
1 1 Clear Key
1 2 Reset Key
SYMBOL
3 1
2
3
2
4
7
5
6
7
5.5
65.0
NOTICE
1. Have the Timer installed only by qualified electrical workers.
2. Use the Timer within the specified ratings for operating
temperature and humidity.
3. The Timer is not waterproof or oil resistant. Do not use it in
locations subject to water or oil.
Do not use the Timer in locations subject to excessive dust,
corrosive gas, or direct sunlight.
4. Be sure to wire the terminals correctly and correct polarity.
5. Take adequate protective measures (such as a breaker, or
fuse)for the power supply of the Timer.
6. Do not touch the input terminal while power is being
supplied; touching live terminals may result in electric shock.

SPECIFICATIONS

Rated Voltage
Voltage Range
Contact Rating
Backlight
Mounting & Socket
Indicator Operating
Life
Dielectric Strength
Power Consumption
Ambient Temperature
Ambient Humidity
Weight
NAME
Display working status (See DISPLAY DESCRIPTION table)
ON: Green light OFF: Red light
Shift key of clock setting
Weekday setting
12/24H Key Hour setting /
Minute setting
Select Key Second setting /
Keep output cantact state open or close /
Start program ; Star or pause program in twin timer mode
Mode function setting
Program number setting Maximum of 80 programs ON/OFF
Clear setting
Hold down 2 seconds to reset and restore manufature default
DESCRIPTION
Display AM or PM
,
Display hours minutes and seconds
Display weekly
Display program ON or OFF
Display program number
Display twin timer mode
Display output status
13.0
APT1 + Y-50 + US-08
Y-50
100~240VAC/DC 12~60VDC/AC 50/60Hz ;
Rated 90~110%
250VAC 15A Resistive load
With Backlight
Surface P2CF-08 :
Flush Y-50+US-08 Y-50+P3G-08 : ;
ON Green OFF Red : ; :
Mechanical: 5000000 times
Electrical: 100000 times
1000V AC for 1 minute between input terminals and case(ground)
1500V AC for 1 minute between output terminals and case(ground)
Approx. 3VA
-10 ~+50
45~85%RH
Approx. 130g
FUNCTION
;
Change clock mode 12H/24H
Memory and backlight option select key
;
TIME ADJUSTMENT
Press
set the current weekday.
Press
set the current hour.
Press
set the current minute.
Press
set the current second.
35.8
100.8
key + key
key + key
key + key
key + key
US-08
