S-9204 SDI Multiviewer and Switcher

1. Introduction

4 SDI Multiviewer via HDMI output
S-9204 is a solution of monitoring 4-ch SDI by a single HDMI television or monitor. There're 3 display patterns:
Quad split display, one channel full screen switch display, and PGM/PVW mode display. Each input SDI has
independent loop through output and supports SDI timecode, embedded audio meter, video title editing on each
displaying window.
Basic Switcher function via SDI output
S-9204 can be used as basic switcher in the PGM/PVW display mode. It supports PGM output via SDI and one
key direct switching from PVW to PGM, with absolute zero delay.

2. Features

4-channel HD/SD-SDI input
4-channel HD/SD-SDI loop through output
Multiview output via HDMI
Quad-split, Full screen, PGM/PVW display modes.
PGM switcher output via SDI, with zero delay

3. Specifications

Input
Output
Format
Audio
Power Consumption
Working Voltage
Working
Environment
Dimension
Net weight
Remark:
(1) All the SDI input should be the same formats in the multiview mode
(2) When there is no recognizable SDI input, the HDMI output format is 1080i50
USER MANUAL
SWIT Electronics Co., Ltd.
HD/SD-SDI
4
×
HD/SD-SDI Loop
4
×
HDMI(Multiview)
1
×
SDI (PGM)
1
×
3.5mm headphone
×
1080p (30 / 29.97 / 25 / 24 / 23.98)
SMPTE-274M
1080i (60 / 59.94 / 50)
SMPTE RP211
1080psf (30 / 29.97 / 25 / 24 / 23.98)
SMPTE-296M
720p (60 / 59.94 / 50)
ITU-R BT.656
576i (50)
SMPTE-125M
480i (59.94)
48KHz Sync
8 W
DC12V
Temperature: 0
C -+40
°
19inch/1U
4 83
4 5
×
×
1440g
Output SDI embedded audio via 3.5mm socket
SDI embedded audio meter (2-ch) display
SDI time code display
Customer editable video title for each input channel
19-inch 1U rack mount
1
SDI input
C , Humidity:10%-90%
°
2 51 mm
Ver:V1.1.0V01
Tel:+86-25-85805753
Fax:+86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
HDMI multiview output
Same as SDI input format
Same as SDI input format
Same as SDI input format
Same as SDI input format
1080i60
1080i50
