PRODUCT MANUAL
Easy Lock Fold Down Clotheslines
Single Model Pictured
IMPORTANT – READ THE PRODUCT MANUAL BEFORE USING YOUR CLOTHESLINE
SUITABLE FOR MODELS
MINI 7.5m
SLIM 11m
SINGLE 22m
100% Australian Owned Since 1954
Product Code
Date of purchase
Name & location
of supplier
1219-V2
daytek.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DAYTEK MINI

  • Page 1 PRODUCT MANUAL Easy Lock Fold Down Clotheslines Single Model Pictured IMPORTANT – READ THE PRODUCT MANUAL BEFORE USING YOUR CLOTHESLINE SUITABLE FOR MODELS Product Code MINI 7.5m Date of purchase SLIM 11m Name & location SINGLE 22m of supplier 1219-V2 daytek.com.au...

  • Page 2: Before You Begin

    Your carton should contain the following: installation below A. Wall Bracket x 2 2. Free standing – use Daytek Ground Mount Kit B. Side Arm & Strut Assembly x 2 *Sold separately (available in standard in ground C. Front Bar x 1 installation or with base) D.

  • Page 3: Wall Mounting Installation

    INSTALLATION PROCEDURE Mounting Width Centre to centre fixing points for installation, 1. MOUNTING LOCATION Mini — 1520mm / Slim, Single — 2220mm For best drying results, select a location that Mounting Height receives maximum sunlight and airflow. The recommended mounting height for the top hole...
  • Page 4 INSTALLATION PROCEDURE (Continued) 2. MOUNT THE WALL BRACKETS 2.1 Use a Wall Bracket as a guide to mark the 2.2 Drill the marked hole positions to suit your fixing hole positions for one side of the wall fasteners. clothesline. (See Figure 2A) If you are using an anchor bolt, tap the bolt Make sure to align the top hole of the Wall into the holes as per the manufacturer’s...
  • Page 5 3. ATTACH SIDE ARMS AND STRUTS 3.1 Press 4 x Wall Bracket Bushes into each Side Arm & Strut Assembly (See Figure 3A) 3.2 Fasten a Side Arm & Strut Assembly to each Wall Bracket using the supplied Nuts & Bolts (13mm) (See Figures 3B–3D) NOTE: Do not overtighten the nuts.
  • Page 6 INSTALLATION PROCEDURE (Continued) 5. THREAD CLOTHESLINE AND TENSION 5.4 Progressively pull each line tight working the slack from the rear line to the front line. 5.1 Thread the cord through the inner most hole 5.5 Pull the cord tight through the tensioner and (closest to wall) and tie off with a knot (see Figure 5A).
  • Page 7 OPERATING THE CLOTHESLINE TO RAISE TO LOWER Grip the centre of the Front Bar with one or two Grip the centre of the Front Bar and gently lift the hands as shown below. clothesline upwards to the maximum point of travel. This will unlock the strut mechanism allowing it to Gently raise the bar to the maximum point of travel fold down flat.

  • Page 8: Care And Maintenance

    You are entitled to a replacement or refund for and remedies of the consumer under law. a major failure and for compensation for any Where it is deemed necessary, Daytek will arrange loss or damage. You are also entitled to have the for the inspection of your product.
