Small-Blade Holder
®
The Veritas
allows you to effectively and safely
sharpen small blades, such as
those found on most spokeshaves
(including the Veritas
Spokeshave, 05P32.01), instrument
makers planes, etc. The blade is
securely held in place by two
powerful rare-earth magnets and an
adjustable stop block. The small-
blade holder transforms your small
blade into a much larger one so it can
be adequately held for sharpening,
either by hand or by mounting in a
Honing guide. The included spacer
and long machine screw allow it
to be used with the Veritas
Jig (part of the Veritas
System, 05M02.10).
Instructions
Position your blade on the holder as shown in Figure 2, with the bevel
down and the cutting edge projecting approximately
screw securing the stop block. Slide the stop block forward until it
contacts the back edge of the blade and tighten the screw. Subsequent
sharpening of the same blade will not require this set-up; just locate
the blade on the holder and slide it back until it makes contact with the
stop block.
1
/
8
Figure 2: Positioning the blade.
Small-Blade Holder
®
Low-Angle
®
®
Sharpening
"
Blade
Long Screw
Spacer
Angle
Figure 1: Small-blade holder.
Small-Blade Holder
Stop Block
Stop Block
Rare-Earth Magnet (2)
View Underneath
1
/
8
05P32.03
Body
". Loosen the
Advertisement
Table of Contents
Summary of Contents for VERITAS 05P32.03
- Page 1 The included spacer and long machine screw allow it ® to be used with the Veritas Angle View Underneath ® Jig (part of the Veritas Sharpening System, 05M02.10).
- Page 2 Sharpening System The long machine screw and spacer provided allow the small-blade holder ® to be used with the Veritas Sharpening System. Simply remove the knurled brass knob that clamps the pentagon wheel to the angle jig. Position the spacer between the angle jig base and the pentagon wheel and secure in place with the long machine screw.
