Summary of Contents for buchel 49-56
- Page 1 Quick Start Guide 49-56 Micrometer GM Pro 7.4...
- Page 2 In order to communicate the micrometer and the PC must be connected using a cable RS232 serial null modem (Buchel item no: 611-035). In case the PC has no RS232 it is allowed to use a RS232-USB converter (Buchel item no: 611-041).
- Page 3 Connect device Press Options Press Graph Press Serial...
- Page 4 Connect device Press Return Press Return...
- Page 5 Activate device Double-Click on GraphMaster...
- Page 6 Activate device Click on Add Device...
- Page 7 Activate device Type the model “49-56”...
- Page 8 Activate device Click on Install...
- Page 9 Activate device Click on Yes...
- Page 10 Activate device Click on Next...
- Page 11 Activate device Turn OFF the instrument Plug the cable...
- Page 12 Activate device Click on Next...
- Page 13 Activate device Wait the scan...
- Page 14 Activate device Turn ON the instrument...
- Page 15 Activate device Press Next...
- Page 16 Activate device Press Next...
- Page 17 Collect the tests Double click on 49-56 Micrometer...
- Page 18 Collect the tests Fill the identification...
- Page 19 Collect the tests Click on OK...
- Page 20 Collect the tests The software is waiting the data...
- Page 21 Collect the tests Press Test Run the tests Load the sample Press Start...
- Page 22 Collect the tests The software is receiving the data...
- Page 23 Collect the tests Click on New Test or Exit To save the data...
- Page 24 Collect the tests Click on Yes...
