PG3
6. Attached scoring system securely to pole.
* Place scoring system in pre-defined
location on side of table.
* Secure scoring system with four (4) flat head
screws.
* Connect scoring system cable and sensor
cable to junction box.
ASSEMBLY INSTRUCTIONS
NOTE:
Please carefully read through instructions once before proceeding with assembly.
(1) Heavy load, 2 or more adults are recommended to assemble.
(2) Proper lifting posture is recommended to avoid injuries.
(3) Table contains small parts & components not suitable for children.
(4) Table contains joints and connecting parts. Care should be taken during stowage &
assembly
(5) Products is free standing. Efforts should be made to ensure product is used on even
surface.
COMPONENTS:
Part Description
Leg Bolt:
1
Washer:
2
Leg Leveller
3
Round end panel screw
4
Flat head scorer screw
5
Table Legs
6
Legs Panel
7
Scoring System
8
Air Hockey Table
7SMGIAAH07
GIAAHT07
Quantity
12
12
4
12
4
4
2
1
