CYPRES CapSense Quick Start Manual

CY3280-BBM UNIVERSAL C
1
Introduction
1. The CY3280-Bread Board module kit
connects to any CY3280 Universal
CapSense Controller (UCC) board,
such as the latest CY3280-20x66 DVK.
This helps in evaluating the various
PSoC features.
3
Board Setup
2. The CY3280-BBM provides access to
every pin routed to the 44-pin connector
on the attached UCC board.
3. Use the prototyping area (described in
Step 4) to evaluate the PSoC features.
®
S PROTOTYPING MODULE KIT
AP ENSE
QUICK START GUIDE
2
Board Setup
1. Connect the CY3280-BBM board to the
P2 connector of any Universal CapSense
Controller (UCC) board such as the
CY3280-20x34 (to be purchased
separately).
4
Module Description
1. The vertical holes on the bread board
from A to H, B to C, G to F, and D to E
are shorted; the horizontal holes from A
to B, H to C, G to D, and F to E are
isolated from each other.
2. To bring out port pins, connect the port
pin headers on to the bread board with
wires.
A
H
G
F
B
C
D
E
