Summary of Contents for jtc S32H5112J
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT INSTRUCTIONS ......................... 1 SAFETY INSTRUCTIONS ..............................1 BATTERY HANDLING AND USAGE ............................ 2 FEATURES ............................... 2 TV STAND INSTALLATION ..........................3 GENERAL PARTS ............................4 MAIN UNIT ..................................... 4 REMOTE CONTROL ................................6 REMOTE CONTROL PREPARATION ..........................8 BATTERY INSTALLATION ............................... -
Page 3: Important Instructions
Do not subject the product to violent shocks, extreme temperatures, or lengthy periods or direct sunlight. Keep the product away from magnetic objects, motors, and transformers. Do not use outdoors in inclement weather. Do not use the TV while driving; this is dangerous and is illegal in some areas. GT06-S32H5112J EN/1908.V01... -
Page 4: Battery Handling And Usage
USB MULTIMEDIA PLAYBACK MULTI-LANGUAGE ON-SCREEN-DISPLAY FULL FUNCTION REMOTE CONTROL INPUTS: HD-INPUT, YPbPr, AV, CI, VGA, PC AUDIO, SCART CI PLUS (CI+) COMPATIBLE WI-FI (802.11b/g/n) & LAN (RJ45) CONNECTION COAXIAL OUTPUT EARPHONE OUTPUT GT06-S32H5112J EN/1908.V01... -
Page 5: Tv Stand Installation
Step 3 Tighten the included screws with a screw driver. NOTES: 1) Unplug the power cord first when installing or removing the TV Stand. 2) Contact one or more partner for assistance when installing or removing the TV stand. GT06-S32H5112J EN/1908.V01... -
Page 6: General Parts
To increase/decrease the volume level or move will display blue color. left/right. 3. Stand Holder 6. CH +/- Button: To select next/ previous channel or move up/down. 7. MENU Button: To enter menu setting page. 8. SOURCE Button: To select the input source. GT06-S32H5112J EN/1908.V01... - Page 7 11. EARPHONE output terminal 5. VGA input terminal 12. RF input terminal - To connect the external Satellite TV Antenna (DVB-S2) 13. RF input terminal - To connect the external TV antenna (DVB-T/DVB-T2/DVB-C) 14. PC AUDIO input terminal GT06-S32H5112J EN/1908.V01...
-
Page 8: Remote Control
Enter Media (USB) mode directly. Start/Pause playing. Move fast forward Move fast backward No function for this model. Stop playing : Play the next file. INDEX (DTV): Display the record list or Teletext index. Play the previous file. GT06-S32H5112J EN/1908.V01... - Page 9 “Navigation mode”, use LEFT/RIGHT or UP/DOWN navigation buttons to scroll the page horizontally or vertically.); press it three times to and wait about 5 seconds till “Mouse” Play the next/previous program. icon disappeared, now you have entered primary “Remote Control” mode. GT06-S32H5112J EN/1908.V01...
-
Page 10: Remote Control Preparation
Remote Control Push sensor. Sensor Do not place objects between the Remote control and the remote control Sensor. Open Do not use this remote control while simultaneously operating the remote control of any other equipment. Press GT06-S32H5112J EN/1908.V01... -
Page 11: Basic Connection
CONNECTING TO AC POWER SOURCE Main Unit To power outlet CONNECT EXTERNAL ANTENNA TO UNIT Install external antenna into antenna jack for best picture. Antenna Outdoor antenna amplifier Indoor antenna amplifier 75 OHM Power plug of antenna plug antenna amplifier GT06-S32H5112J EN/1908.V01... -
Page 12: Hd-Input Connection
(Not included) Back of BD/DVD/DVR PC/VGA CONNECTION Use VGA cable and Audio cable (not included) to connect the unit VGA Cable Audio Cable with TV or PC, and use this (Not included) (Not included) product as a monitor. GT06-S32H5112J EN/1908.V01... -
Page 13: Scart Connection
(Not included) Back of BD/DVD/VCR AV (COMPOSITE VIDEO) CONNECTION For basic connection, use the composite Audio L/R (white/red) and CVBS (yellow) cable (not included) AV Cable to connect the unit with other devices. (Not included) Back of BD/DVD/VCR GT06-S32H5112J EN/1908.V01... -
Page 14: Ypbpr Connection
Use a LAN cable (not included) to connect this TV with available network. LAN Cable (Not included) USB CONNECTION Insert a USB memory device (not included) to playback MOVIE / MUSIC / PHOTO / Multimedia files. USB Memory Device (Not included) GT06-S32H5112J EN/1908.V01... -
Page 15: Insert Ci Card
CONNECT EARPHONE TO THE UNIT Earphone Cable (Not included) Make sure all the equipment and power cords are connected properly and the unit is set in correct mode before operation. GT06-S32H5112J EN/1908.V01... -
Page 16: Basic Operations
- Press UP/DOWN navigation button to select preferred program. - Press LEFT/RIGHT navigation button to switch between left column and right column. - When a program is highlighted in the middle column, press OK button to set a reminder. GT06-S32H5112J EN/1908.V01... - Page 17 Press TV/RADIO button on remote control to switch between TV and radio mode. SUBTITLE Press SUBTITLE button on remote control repeatedly to select desired subtitle. NOTE: To enable this function, make sure that the channel you are viewing supports multi-subtitle. GT06-S32H5112J EN/1908.V01...
-
Page 18: Starting
Press LEFT/RIGHT/UP/DOWN navigation buttons to select desired option, and press OK button to confirm selection. Press EXIT button to return to previous page. Welcome Press RIGHT navigation button to enter next page. Language Setting - Press UP/DOWN navigation button to select your language. - Press RIGHT navigation button to enter next page. GT06-S32H5112J EN/1908.V01... -
Page 19: Smart Tv Operation
Press SMART TV button to enter Home page. NOTES: - For more convenient operations, connect external Mouse (not included) to USB slot. - External Mouse operations: Click the LEFT button: Select an option or enter submenu. Click the RIGHT button: Back to previous page. GT06-S32H5112J EN/1908.V01... -
Page 20: Browser
- Press OK/ENTER button to open the on-screen keyboard. - Then use UP/DOWN/LEFT/RIGHT navigation buttons to select desired option and press OK/ENTER button to confirm input. - When inputting finished, select “Go” on screen and press OK/ENTER to enter a webpage. GT06-S32H5112J EN/1908.V01... -
Page 21: File Manager
- Use UP/DOWN/LEFT/RIGHT navigation buttons to select “Application manager” on HOME page and press OK/ENTER button to open it. - You can install an application from internal memory or external USB device; uninstall a new installed application; clean memory. GT06-S32H5112J EN/1908.V01... -
Page 22: Settings
(Note: Make sure your device supports Wireless Display function and used the same wireless network with this product.) System Upgrade Upgrade the system. Restore to Factory Settings Reset the product to factory default setting. About Display Smart TV system information. GT06-S32H5112J EN/1908.V01... -
Page 23: Main Menu
- Move the cursor up/down to select ATV or DTV manual tuning and press OK to enter submenu. ATV Manual Tuning Channel: select a channel number. Color System: select available color system. Sound System: select available sound system. GT06-S32H5112J EN/1908.V01... - Page 24 Key Lock: Turn on/off the keyboard lock. Source Lock: Turn on/off the lock of available sources. Boot Information Settings: Set boot interface or default source. Max Volume: Set the maximum volume level. Default Volume: Set the default volume level. Clear Lock: Clear above settings. GT06-S32H5112J EN/1908.V01...
-
Page 25: Picture
When Picture Mode is selected [User], press OK/ENTER to enter submenu and adjust brightness, contrast and so on information. 2.2 Color Temperature This item is used to adjust the optimum color temperature for suitable viewing. Available options: Standard, Warm, Cool. GT06-S32H5112J EN/1908.V01... -
Page 26: Sound
This item is used to turn on/off Hearing Impaired function. For Hearing Impaired users, this function can assist help to know a certain scene or action through the caption, instead of hearing it. NOTE: Hearing Impaired function works only when you are viewing programs that contain related caption information. GT06-S32H5112J EN/1908.V01... -
Page 27: Advance
Blue Screen is ON. 4.7 HDMI CEC Press OK/ENTER button to enter it. To use HDMI CEC function: - Make sure the HDMI device (Amplifier, etc.) is connected correctly. GT06-S32H5112J EN/1908.V01... -
Page 28: Atv And Other Modes
- Select “Channel” using navigation buttons and press RIGHT button to enter it. - Then highlight “Dish Setup” and press OK to enter it. - Press LEFT/RIGHT navigation button to highlight Left, Middle or Right column. - Press MENU button to return. GT06-S32H5112J EN/1908.V01... - Page 29 (3) Press BLUE button on remote control to enter Scan menu. - Press UP/DOWN navigation button to highlighted desired item. - Press LEFT/RIGHT navigation button to select desired Channel Type, Service Type and Scan Mode. - Then press OK to scan programs automatically. GT06-S32H5112J EN/1908.V01...
- Page 30 Press LEFT/RIGHT navigation button to select desired option. Motor Press LEFT/RIGHT navigation button to select desired option. Single Cable (also known as “One Line Technology”) Press OK button to enter submenu. Then use navigation buttons to select desired option. GT06-S32H5112J EN/1908.V01...
-
Page 31: Maintenance
Do not wall mount the TV while TV is turned on. It may cause personal injury due to electric shock. Use standard M6 screws (10 mm / 4 pieces) to mount this TV. Back of your TV GT06-S32H5112J EN/1908.V01... -
Page 32: Specifications
Sound System BG, DK, I, L; NICAM/A2 Storage Channels 100 CH Teletext 1000 pages DTV SYSTEM Receiving Range 48.5 - 2150 MHz Input Impedance 75 Ω Channel Bandwidth 7 MHz / 8 MHz Modulation (DVB-T) COFDM QPSK, 16QAM, 64QAM GT06-S32H5112J EN/1908.V01... - Page 33 732 (W) x 191 (D) x 480 (H) (with Stand) 732 (W) x 81 (D) x 434 (H) (without Stand) Weight Approx. 4.0 Kg (with Stand) Approx. 3.9 Kg (without Stand) *Specifications are subject to change without notice GT06-S32H5112J EN/1908.V01...
-
Page 34: General Troubleshooting
● Check the audio settings. ● Press MUTE button on remote control to cancel mute function. ● Unplug the headphone. Noise or other interface Electronic equipment near the unit is causing interface. Relocate the unit or move the equipment. GT06-S32H5112J EN/1908.V01... - Page 35 Built-in 802.11b/g/n Wireless Adapter (Frequency in the 2.4 GHz & 5.0 GHz band) Applications of all channels in all European countries are allowed by ETSI (European Telecommunication Standards Institute). The device can only be used within range of Wi-Fi enabled channels of 802.11b/g/n. GT06-S32H5112J EN/1908.V01...
