Summary of Contents for dtm MICRO2
- Page 1 MICRO2 / MICRO2 868 / MICRO2 Duo 2 - C H A N N E L R A D I O R E C E I V E R Installation and assembly v. 2.1 automation system...
- Page 2 GENERAL INFORMATION A series of MICRO2 two-channel receivers is designed to work with gate drivers, roller shutters, and other automation devices, where the control pulse is required. It provides a simple and inexpensive way to expand the functionality of the installation of a remote control.
-
Page 3: Receiver Installation
- the negative impact of dense development, humid or concrete walls, - reducing the range of remote with used battery, - increasing the range with increasing the height of the receiver antenna. DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa... - Page 4 MICRO II screw terminal description DTM System MICRO2 MICRO2 868 MICRO2 Duo Made in Poland version of receiver signaling USB connector Fig. 2. View of the receiver board with description. DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa...
-
Page 5: Receiver Programming
2. RECEIVER PROGRAMMING MICRO2 receiver has ability to program parameters of work. Before programing refer to Figure 2. showing view of mainboard, programming buttonsC1 andC2 and LEDs location. 2.1 Adding remote to receiver memory When receiver is on the working mode, press and hold programming button of chosen channelC1/C2. Red LEDC1/C2 lights on, then press chosen remote button.Successful adding is indicated by LEDC1/C2 blinking. - Page 6 PRESS AND HOLD C1 AND C2 LIGHT UP ALTERNATELY RELEASE BUTTON WHEN RELEASE BUTTON WHEN C2 ON C1 ON - EASY ADDING LOCKED - EASY ADDING UNLOCKED Fig.6. Locking/unlocking easy remote adding. DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa...
- Page 7 2.5. Entering of authentication code (unable for MICRO2 version) Galactic function allows adding remotes programmed and configured outside the installation, without need to use receiver buttons. It is necessary to have remote with Galactic function, remote has to be programmed with authentication code by GPROG programmer.
- Page 8 2.7.Adding the remote with the use ofGalactic function (not available for MICRO2 version) The condition of the success of adding the remote with the use of the Galactic function is the compatibility of authentication codes set in the receiver and the remote.
- Page 9 C1/C2 + MOM / MONO / BIST TO LIGHT MOM/BIST LED AND HOLDING C1/C2 Fig.13. Setting bistable or momentary mode. Pressing the other channel button while programing will leave procedure without saving. DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa...
- Page 10 FAST AND THEN GOES OUT OF SECONDS/MINUTES RELEASING BUTTON PRESSING C1/C2 WHILE AT THAT MOMENT MONO LED BLINKS FAST SET THE 0,5s TIME WILL SET THE TIME IN MIN. Fig.14. Setting the monostable mode. DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa...
- Page 11 During the backup and update of the remotes using the MEMO programmer receiver remains inactive, it does not respond to the signal from the remotes. In case of activated service lock, receiver cooperation with the programmer is not possible. DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa...
-
Page 12: Warranty
This time is counted according to the producer warranty labels or serial numbers placed on every product. DTM System obliges itself to repair the device for free if during the warranty period there are problems which come because of its fault. Broken device should be supplied on customer’s expense to the place of purchase and enclose...
