Bike Rack Operating Instructions
Cora Bike Rack - E3DT-GP Rack Series
Operating Instruction - Double tier pivoting bottom rack
2
Racks can be pivoted to increase
access for racking or removal.
Wheel
well
Lock loop
Lock loop
E3GP-B
E3GP-F
E3GP-B
E3GP-F
Wheel
well
1
Choose either the E3GP-B or E3GP-F
E3GP-B - Back wheel in first
E3GP-F - Front wheel in first
E3GP-B
Place bike within the wheel wells, front
or rear wheel first depending on rack
selected.
Secure bike to locking loop using
personal locking device.
For security reasons CORA recommends
the lock passes through the bike frame.
E3GP-F
E3GP-B
PH 1800 249 878
sales@cora.com.au
www.cora.com.au
Rev 1.00 Feb 2020 ©
