Summary of Contents for MA lighting Network Switch
- Page 1 Version 3.3 | 2017-04-24 English...
-
Page 2: Table Of Contents
Change Group Name 5.6. Edit IGMP Snooping 5.7. Edit IGMP Querier 5.8. Edit Unknown Flooding 5.9. Change VLAN ID © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 3 Get Switch Configuration 7.11. Edit Port Mirroring 7.12. Upload Switch Configuration 7.13. Reset Settings Specifications Support Glossary Index © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 4: Introduction
The MA Network Switch is housed in a typically robust 1RU chassis, with color coded filter and data indicators front and rear. The front panel features a single etherCON port and display screen. The rear panel incorporates 8 etherCON ports and 2 SFP cages to suit mini-GBIC fiber connections. -
Page 5: Intended Use
Figure: Principle Network Schematic 1.1. Intended Use The MA Network Switch is intended to be operational right out of the box as a standard switch. In the default configuration, it will forward packets between connecting devices after power up. Every other use is not intended and could follow personal injury and damage to property. -
Page 6: General Safety Instructions
Apple Safari 8 To use the online help manual, you need internet access. 1.5. SFP Transceiver Compatibility © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 7 MA N e t w o r k S w i t c h U s e r Ma n u a l Version 3.3 1.5. SFP Transceiver Compatibility The following SFPs transceivers are tested and compatible with the MA Network Switch. Cisco MGBT1 Gigabit 1000 Base-T Mini-GBIC SFP Transceiver Cisco MGBSX1 Gigabit SX Mini-GBIC SFP Transceiver...
-
Page 8: Device Overview
MA N e t w o r k S w i t c h U s e r Ma n u a l Version 3.3 2. Device Overview The following chapter gives you an overview about the device of the MA Network Switch. 2.1. Front Panel 13 x Link LEDs... -
Page 9: Led Indicators
8 x etherCON Link LEDs 8 x etherCON Group LEDs 1 x powerCON Connector 2.3. LED Indicators © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 10: Factory Defaults
MA N e t w o r k S w i t c h U s e r Ma n u a l Version 3.3 2.3. LED Indicators The following tables shows the LED indicators for the MA Network Switch along with the explanation of each indicator. Power LED... - Page 11 MA-Net2 data IPv4 Preset dot2-Net The preset dot2-Net contains the following filters by default: dot2-Net wing data dot2-Net wing © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 12 SSH (sport 22) syslog AVAHI SNMP trap SNMP KiNet Art-Net sACN MA-Net2 ctrl IPv4 MA-Net2 data IPv4 © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 13 The following tables describes what filters exist by default along with their frame match and what will happen to the filters when you reset the switch. Filter Frame Match PSN Standard IPv4 UDP dport 56565 © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 14 SMB (tcp 139) TCP dport 139 SMB (udp 138) UDP dport 138 SMB (udp 137) UDP dport 137 © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 15 CITP UDP dport 4809 ShowNet UDP dport 2501 PathPort UDP dport 3792 ETC Net2 UDP dport 6107 © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 16: First Steps
Keep the packing material for transport. 3.2. Install Mini-GBIC (SFP) The MA Network Switch comes with up to four SFP cages. These cages accept mini-GBIC transceivers. Two are at the rear panel, port 9 and 10. Two are inside the MA Switch. -
Page 17: Connect The Hardware
Version 3.3 3.3. Installation in a Rack The MA Network Switch is 1U high and will fit in most standard 19-inch racks. 1. Insert the switch into the 19-inch rack and secure with suitable screws. Ensure the ventilation holes are not obstructed. -
Page 18: Access The Web Interface
The PC is set to a compatible IP address. 3.6. Access the Web Interface Follow these steps to access the web interface of the MA Network Switch. Requirements: © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany... - Page 19 We recommend to change the password after the first login. The status page of web interface opens. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 20 MA N e t w o r k S w i t c h U s e r Ma n u a l Version 3.3 MA Network Switch – web interface © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 21: Display Navigation
If the background of a port starts to flash in red, the workload of the port is over 80 %. In bottom right corner the version number is displayed. 4.2. Name View © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 22: Workload View
SFP B Front Port The version of the MA Network Switch is displayed in the right corner at the bottom of the name view. 4.3. Workload View © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany... -
Page 23: Lag View
The percentage and the green load bar on every port, displays the in and out total network load per port. In bottom right corner the version number is displayed. 4.4. LAG View © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 24: Reset View
Name View. The version of the MA Network Switch is displayed in the right corner at the bottom of the LAG view. 4.5. Reset View To open the reset view, press and hold the menu button for about 5 seconds. -
Page 25: Ports / Groups
The port description is applied and saved in the startup configuration. The port description is visible in the web interface overview. 5.2. Assign Groups to Ports © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 26 Use port 13 on the front panel as management port to connect the PC for switch configuration via the web interface. Assign Groups © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 27: Edit Rstp
The MA Network Switch supports an implementation of RSTP that is compatible with the IEEE 802.1w standard and that does not support RSTP per VLAN. This means that the MA Network Switch sends and expects to receive untagged RSTP messages. -
Page 28: Edit Speed Setting
RSTP is required. If you then disable RSTP, there is no connection. 5.4. Edit Speed Setting You can edit the port speed of each port on the MA Network Switch. The selected speed is visible at the status page on the web interface. -
Page 29: Edit Igmp Snooping
3. Click The new group name is applied and saved in the startup configuration. 5.6. Edit IGMP Snooping © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 30: Edit Igmp Querier
IGMP snooping is enabled or disabled for the selected group, and saved in the startup configuration. 5.7. Edit IGMP Querier © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 31: Edit Unknown Flooding
IGMP querier is enabled or disabled for the selected group and saved in the startup configuration. 5.8. Edit Unknown Flooding © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 32: Change Vlan Id
3. Click Unknown flooding is enabled or disabled and saved in the startup configuration. 5.9. Change VLAN ID © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 33 4. Click The new VLAN ID for the group is applied and saved in the startup configuration. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 34: Presets / Filters
MA-Remote MA-Net1 grandMA2 sACN Important: Use presets only if a filter function is required. If you use the MA Network Switch in a MA System it is not mandatory to use the grandMA2 preset. For more information, see apply presets. -
Page 35: Assign Presets To Ports
IPv4 protocol nr 2 (IGMP) DHCP client IPv4 UDP port 68 DHCP IPv4 UDP port 67 6.1. Assign Presets to Ports © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 36: Apply Filters To Ports
If a filter is set to allow, all other network packets not matching this filter, will be blocked © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 37 If allow is selected, all network packets matching the filter port will be forwarded. If a protocol needs more than one port, you have to apply multiple filters. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 38: Create New Presets
Applied Filters to Ports. Information: The new preset will be applied for the selected port after saving. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 39: Update Presets
6.4. Update Presets © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 40: Create New Filter
The combination of filter name, data type and addressing must be unique for each filter. If this data are not unique, it is not possible to create a new filter. Open Edit Filters pop-up © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 41 Figure 1: Edit filters pop-up The edit filters pop-up is open. Create Ethernet Filter To create an Ethernet filter: © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 42 (= destination port number). Valid port numbers are between 0 - 65535. IPv4 destination 7. Enter the © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 43 If you already have a filter configuration for a new filter, you can paste the configuration data into the field. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 44: View Filter Data
1. Click Extended filter and preset config 2. Scroll down to the end of the page and click © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 45 4. Select the filter you want to view in the drop down. View filter 5. Click A pop-up opens what displays the filter data. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 46: Delete Presets
MA N e t w o r k S w i t c h U s e r Ma n u a l Version 3.3 Figure 2: View Filter pop-up 6.7. Delete Presets © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 47: Delete Filter
If you have created custom filters that you no longer use or need, you can delete them. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 48 Figure: Edit Filters pop-up 4. Select the filter you want to the delete in the drop down. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 49 If the filter you tried to delete is contained in a preset, a warning asks if you want to delete this filter anyway. 6. Click The selected filter is deleted from the startup configuration. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 50: General Settings
Edit general settings The following topics describe how to edit the general settings of the MA Network Switch. 7.1. Change Name © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany... -
Page 51: Change Id
Apply settings and leave edit 3. Click The MA Network Switch has a new ID. The new ID is saved in the startup configuration. 7.3. Change DHCP Client © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany... -
Page 52: Change Ip Address
The IP address is changed and saved in the startup configuration. To access the web interface, type the new IP address field Enter address in the of the browser and press 7.5. Change Subnet Mask © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 53: Change Default Gateway
You can change the password of the MA Network Switch. The password is necessary to login into the web interface. admin The default password is © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 54 4. Type the new password and click The password is changed and you are logged in with the new password. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 55: Update Firmware
7.8. Update Firmware You can update the firmware of the MA Network Switch. The current firmware is displayed in the right corner at the bottom of the MA Network Switch display and in the web interface. Download the latest version of the switch on www.malighting.com. - Page 56 Tools / Edit General Settings 1. Click Update firmware 2. Click Fallback to this firmware 3. Click A warning pop-up appears. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 57: Get Switch Configuration
Version 3.3 Downdating to older firmware 4. Click The MA Network Switch starts to install the backup firmware and then reboots. 7.10. Get Switch Configuration © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... -
Page 58: Edit Port Mirroring
7.11. Edit Port Mirroring In Port Mirroring, the entire traffic that arrives at a port is mirrored onto a mirror port of the MA Network Switch. It is most commonly used in debugging or for the analysis of the network traffic such as the network load. - Page 59 MA N e t w o r k S w i t c h U s e r Ma n u a l Version 3.3 Important: The MA Network Switch mirrors several source ports to one destination port. Vice versa, it is possible to set a single destination port at a time. Use the Web Interface...
-
Page 60: Upload Switch Configuration
If you are not sure how to write the configuration file, get the current switch configuration and modify this file. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 61 The switch configuration is uploading. The update screen opens. Figure 2: Update Screen The update process can take about 60 seconds. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 62: Reset Settings
7.13. Reset Settings By resetting the MA Network Switch, you return the switch to the state it was in when it was first time powered. This is useful for troubleshooting problems that might be caused by manual changes after first time powered. -
Page 63: Specifications
Address Learning / Aging Self learning, Auto aging Switching Throughput 32Gbps IGMP Support IGMP Snooping Port Features © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 64 -10 °C to +60 °C Storage Temperature 14 °F to 140 °F Humidity (non condensing) 20% to 80% relative humidity Physical © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 65 3,7 kg Weight with optical fiber connector 8.2 pounds Approvals EN 55103-1 EN 55103-2 EN 60950-1 RoHS Compliance © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
-
Page 66: Support
Training. Technical Service and Support MA Lighting and its extensive distributor network offer an unparalleled technical service. Call on our expertise for help with any problem, no matter if it is regarding operation, software features, software installations or trouble shooting. -
Page 67: Glossary
Used by network devices for advertising their identity, capabilities, and neighbors on an IEEE 802 local area network. LLDP will be disabled or enabled along with RSTP. For more information, see Edit RSTP. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 68 The Gbic is typically employed in fiber optic and Ethernet systems as an interface for high-speed networking. The data transfer rate is one gigabit per second (1 Gbps) or more. There are two Mini-Gbic cages at the rear panel and two inside of the MA Network Switch. RSTP...
-
Page 69: Index
Delete Filter 6.8. Delete Presets 6.7. Description 5.1. Device Overview DHCP 7.3. Display Navigation Edit Filters Pop-Up 6.5. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com... - Page 70 Install mini-GBIC 3.2. Installation in a Rack 3.3. Intended Use 1.1. Introduction IP address 7.4. IPv4 3.5. 4.4. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 71 6.1. Preset Defaults 2.4. Presets Priniciple Network Schematic 4.1. Rack Installation 3.3. Rapid Spanning Tree Protocol 5.3. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 72 Update 7.8. Update Firmware 7.8. Update Presets 6.4. Upload Switch Configuration 7.12. View 6.6. View Filters 6.6. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
- Page 73 VLAN ID 5.9. Web Interface 3.6. What are Filters What are Presets White Heart 4.1. Workload View 4.3. © 2017 MA Lighting Technology GmbH | Dachdeckerstr. 16 | D-97297 Waldbüttelbrunn | Germany Phone +49 5251 688865-30 | tech.support (at)malighting.com | www.malighting.com...
