Summary of Contents for Commodore AMIGA 10855
- Page 1 AMI GA User's Guide 10855 Color Monitor • Commodore® •...
- Page 2 •...
- Page 3 ® AMI GA User's Guide 1085S Color Monitor (i Commodore ®...
- Page 4 Commodore Electronics Limited. With this document Commodore makes no warranties or representations, either express, or implied, with respect to the products described herein. The information presented herein is being supplied on an "A...
- Page 5 Commodore-Arniga dealer. Also, ail servicing of original or optional devices or equipment, including third-party optional devices or equipment, must be perf ormed by an authorized Commodore service center or Commodore-Arniga dealer. nauthorized installation or servicing will void your warranties.
- Page 6 Monitor The Commodore 10858 is a full-color, 13 inch monitor for use with the Commodore 64 and the Amiga family of computers. The monitor provides audio output in stereo for use with computer systems with stereo capabilities (like the Amiga computers).
-
Page 7: Control Locations And Functions
This chart below indicates the operating modes suitable to the type of computer you are using: Recommended Operating Mode by Computer Model 40-Column display 80-column display Separated Ana log Composite Amiga Control Locations and Functions Before you connect your monitor to your computer, you should familiarize yourself with the location and function of the various control knobs, switches, and ports on both the front and rear of the 1085S. - Page 8 Front view Rear view...
-
Page 9: Connecting The Monitor
Unplug the Computer and the 1085S monitor before installation. lnstalling the 10855 with the power on could cause injury to the installer and damage to the equipment. Commodore will not be responsible for any damages caused by improper installation of the 1085S. - Page 10 Locate the video cable with a 23-pin D connecter on one end and a 9-pin D connec· tor on the other end. To connect the video cable, insert the 9-pin D connecter into the port labeled RGB on the back of your 1085S. Then insert the other end of the cable with the large, 23-pin D connecter into the video port on the back of your Ami·...
-
Page 11: Safety Precautions
3.2. Connecting the Monitor to the Mains (for U.K. only) Your 10858 monitor is designed to operate from an a.c. mains supply of 220-240 volts, 50 If the mains voltage your home is different from this, consul! your dealer. Stabilising circuits ensure satisfactory performance within normal supply variations . -
Page 12: Technical Specifications
Do Not overload AC outlets or extension cords. This result in a shock or lire hazard. more than one plug adapter one power outlet. Do Not Do Not monitor near water or excessive moisture. block the monitor's ventilation slots placing objects on top or underneath Do Not... -
Page 13: Pin Assignment
9-pin D -- RGB Analog 0.7V P-P, 75 ohm with negative composite sync. PIN ASSIGNMENT Pin No. Analog RGB Ground Ground Green Blue Not used Composite Sync. 9 8 7 Not used Not used Sound output: 1.0 W RMS/channel, 5% distortion Audio input signal: 177 mV, 10K ohm Mains voltage:... - Page 16 Printed 1n Korea S/N: 9978615700 scan by leZone 07-2020 http://adzone.free.fr/...
