- Page 1 RANGER 12V AIR COMPRESSOR RANGER 12V AIR COMPRESSOR 4.6M 150PSI DEFLATOR ACCESSORIES COILED FUNCTION INCLUDED WORKING AIRHOSE MAXIMUM PRESSURE K13012 ED1 July 2017...
-
Page 2: Table Of Contents
16. Needle Adaptor 17. Presta Valve Adaptor 18. Carry Bag 19. Deflator Button Part No: ............................K13012 Description: ..........................Ranger 12V Air Compressor Input Voltage: ..........................12VDC Max Current: ..........................30A Max Working Pressure: ......................150PSI Maximum Air Flow: ........................72LPM Temperature Range: ........................ -
Page 3: General Safety Warnings
RANGER 12V AIR COMPRESSOR General Safety Warnings Save all warnings and instructions for future reference. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in serious injury. 1) Work Area Safety a) Keep work area clean and well lit. Cluttered or dark areas invite accidents. -
Page 4: Additional Safety Instructions
RANGER 12V AIR COMPRESSOR 4) Power Tool Use And Care a) Do not use the 12V Air Compressor if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. -
Page 5: Assembly & Operation
RANGER 12V AIR COMPRESSOR Description of Symbols The following symbols could be shown on the tool: Read the instruction manual before Risk of Explosion use. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. - Page 6 RANGER 12V AIR COMPRESSOR Connecting/Disconnecting Adaptors (14, 15, 16 or 17) to the Air Supply Hose (9) WARNING! Ensure the compressor is OFF and disconnected from the power supply before changing adaptors. Gather the accessory you wish to attach your Air Supply Hose (9).
- Page 7 RANGER 12V AIR COMPRESSOR Pumping up Tyres (Schrader Valves) Identify the required pressure for the tyre to be inflated, this is usually displayed on the tyre wall. Remove the desired tyres valve cap from your tyre (Fig 11 and Fig 12).
- Page 8 RANGER 12V AIR COMPRESSOR Pumping up High Volume Inflatables Ensure that the 12V Air Compressor has been disconnected from the power source before installing/unistalling adaptors. Follow the instructions for “Connecting/Disconnecting Adaptors (14,15, 16 or 17) to the Air Supply Hose (9)” located on page 5 to install the appropriate High Volume Adaptor (14 or 15) (Fig 19).
-
Page 9: Troubleshooting & Spare Parts
(14,15,16 & 17). Replace if necessary. The seals are damaged. Contact Kincrome Customer Service on 1300 657 528 . Cleaning & Maintenance WARNING! Before cleaning your 12V Air Compressor or carrying out any maintenance procedure, ensure the 12V Air compressor is switched OFF and disconnected from the power supply. - Page 10 RANGER 12V AIR COMPRESSOR Spare Parts For a full list of available spare parts for this item visit the Kincrome website kincrome.com.au or alternatively contact Kincrome Customer Service. Australian Office Contact Details Phone: 1300 657 528 Fax: 1300 556 005 Email: enquiries@kincrome.com.au...
-
Page 11: Warranty
Warranty Warranty given by Kincrome Tools & Equipment Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria, Australia (Tel +61 3 9730 7100) If this product has materials or workmanship defects (other than defects caused by abnormal or non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement. - Page 12 www.kincrome.com.au...
