- Page 1 Quartzlock E5000 Precision Frequency Engineering MODEL E5000 Low Noise Distribution Amplifier USER’S HANDBOOK E5000 Manual 30 April 2020 Page 0 of 6...
- Page 2 Replaceable Fusing Characteristics ................3 Cleaning Instructions ......................3 Operating Procedure ....................4 Front panel LED Indicator and Status................4 Specification ........................5 Enclosure dimensions: 1U 19 inch rack mount enclosure ..........6 E5000 Manual 30 April 2020 Page 1 of 6...
- Page 3 For continued protections against fire, replace the line fuse(s) with fuses of the same current rating and type (for example, normal blow time delay). Do not use repaired fuses of short-circuited fuse holders. E5000 Manual 30 April 2020 Page 2 of 6...
- Page 4 Clean with a damp (with water) cloth. Never spray cleaner directly onto the unit or let liquid run into any part of it. Never use harsh or caustic products to clean the unit. E5000 Manual 30 April 2020 Page 3 of 6...
- Page 5 One input is provided. This has input impedance of 50 Ohms. The input level can be between -5dBm and +13 dBm. Outputs The E5000 configurable up to 24 outputs. These have source impedance of 50 Ohms, and will provide between +5 and +13 dBm (MAX) into a 50 Ohms load. Front panel LED Indicator and Status...
- Page 6 100Hz <-160 d. 1KHz &10KHz <-168 10. Noise Floor: <-168 11. Spurious Outputs: <-100dBc 12. Broadband Noise: <-145dBm/Hz 13. Delay Match between Outputs: <1ns 14. Delay Input to Output: <6ns E5000 Manual 30 April 2020 Page 5 of 6...
- Page 7 Option 92: 10MHz input 5MHz output Option 93: 10MHz input 1PPS output Option 94: Add POT to adjust the gain of each channel Enclosure dimensions: 1U 19 inch rack mount enclosure E5000 Manual 30 April 2020 Page 6 of 6...
- Page 8 Precision Frequency Engineering Quartzlock 179 • Junction Road • Burgess Hill • RH15 0JW • UK Tel: +44 (0) 1444 232967 E-mail: sales@quartzlock.com Web: www.quartzlock.com Registered in England: 708818 VAT Registration No: GB 190 1166 84 HCD Research Limited trading as Quartzlock...
