Summary of Contents for Essilor DS550
- Page 1 CAMERA DIGITAL DS550 Installation manual www.essilor-instruments.com...
-
Page 3: Table Of Contents
INSTALLATION MANUAL > CONTENTS CONTENTS I. PRESENTATION 1. Accessories provided II. INSTALLATION 1. Equipment installation 2. Software installation a. Activation software b. Perform a new examination... -
Page 4: Presentation
I. PRESENTATION... -
Page 5: Accessories Provided
This guide describes the steps of physical installation as well as the software installation of camera DS550. Prerequisite: installation and set up of the slit lamp has already been performed. 1. Accessories provided The following accessories are delivered with the system:... -
Page 6: Installation
II. INSTALLATION... -
Page 7: Equipment Installation
Remove the ocular block by unscrewing the screw from the upper part of the slit lamp. Using the screw located above microscope of the slit lamp, press then screw on the DS550 digital camera. In the same way, reposition the ocular block. - Page 8 > The system is assembled. Plug in the digital camera Plug the elbow end of the power supply cable for the DS550 camera on the port of the slit lamp designed for this purpose. Camera digital DS550 > v1.0 -03.16...
- Page 9 Then, plug the other end of the power supply cable into the supply port on the DS550 located under the product. > The system is plugged in. Camera digital DS550 > v1.0 -03.16...
- Page 10 Plug the elbow end of the DS550camera connector cable into the camera port designed for this purpose. Then, plug the other end of the connector cable into the 3.0 USB port for the PC. > The system is connected. Camera digital DS550 > v1.0 -03.16...
-
Page 11: Software Installation
The 3.2 Version of AnaEyes allows for the recognition and automatic activation of the software. DS550 digital camera, installed with AnaEyes in version 3.2, functions now like a data-processing key. The P-code, the serial number of the product and other information are contained inside the memory of the camera. -
Page 12: Perform A New Examination
> The device is ready to perform an examination. b. Perform a new examination Click on the icon to access a new examination window. > The following screen is displayed: Click on the icon which corresponds to the slit lamp. Camera digital DS550 > v1.0 -03.16... - Page 13 > The following screen is displayed: > To take a measurement, you only need to press on the button on top of the grip handle. Camera digital DS550 > v1.0 -03.16...
- Page 14 Essilor International (Compagnie Générale d'Optique) S.A. Siège Social : 147, rue de Paris – 94227 Charenton-le-Pont Cedex France 712 049 618 RCS Créteil - www.essilor.com...
