- Page 1 I + M E A C T I A G m b H I + ME ACTIA Informatik und Mikro-Elektronik GmbH Dresdenstr. 17/18 D-38124 Braunschweig Germany Tel.: ++ 49 (0) 531 38701-0 Fax: ++ 49 (0) 531 38701-88 www.ime-actia.com Installation PassThru+ XS 2G (Bluetooth) Ref.: IR 12100 B Seite 1/12...
- Page 2 I + M E A C T I A G m b H © 2009 I+ME ACTIA GmbH All Rights reserved. Any reproduction or distribution of this document, or parts of this document is prohibited without a written authorisation of I+ME ACTIA GmbH.
-
Page 3: Table Of Contents
I + M E A C T I A G m b H Content 1. General ......................4 2. System Requirements ...................5 3. Installation......................6 3.1 Device Discovery ....................6 3.2 Paring Process ....................9 4. Establish a Connection ..................11 4.1 Configure the PassThru+ XS (Bluetooth) device ........... 11 4.2 Connect the Device.................. -
Page 4: General
I + M E A C T I A G m b H ENERAL This document has the intention to describe how to use the PassThru+ XS 2G (Bluetooth) devices from I+ME Actia GmbH. At first the pairing process of the Bluetooth device will be explained. -
Page 5: System Requirements
It will be assumed that you have already installed the third party Bluetooth Dongle and that you have also installed the PassThru API. Furthermore the PassThru+ XS 2G (Bluetooth) device is powered and the distance between dongle and device is not out of range. -
Page 6: Installation
I + M E A C T I A G m b H NSTALLATION EVICE ETECTION Add a new device. Follow the instructions and click the Next-Button. Ref.: IR 12100 B Seite 6/12... - Page 7 I + M E A C T I A G m b H New devices will be searched. A PassThru+ XS 2G (Bluetooth) device has been detected. Ref.: IR 12100 B Seite 7/12...
- Page 8 I + M E A C T I A G m b H Click on the item to select it. Click Next-Button. Ref.: IR 12100 B Seite 8/12...
-
Page 9: Paring Process
I + M E A C T I A G m b H ARING ROCESS Select ‘Use the passkey found in the documentation’. Enter the passkey ‘ACTIA’. Click Next-Button. A Connection will be established. The passkey will be exchanged The device will be installed. - Page 10 I + M E A C T I A G m b H The Outgoing COM port will be the COM port which we have to use for further communication to that device. Click the Finish-Button. Now the installation process is finished. Click the Ok-Button. Ref.: IR 12100 B Seite 10/12...
-
Page 11: Establish A Connection
LUETOOTH DEVICE Launch the “Pass Thru Configurator” from Windows Start Menu. Select the ‘I+ME ACTIA – PassThru+ XS (Bluetooth)’ device. Then, select the previously discovered Outgoing Bluetooth COM port. Click the Ok-Button. Configuration has been finished. Ref.: IR 12100 B... -
Page 12: Connect The Device
The device is connected to the car and is powered via OBD-connector. Start the “Pass Thru Checker” from the Windows Start menu. Select the ‘I+ME ACTIA – PassThru+ XS (Bluetooth)’ device. Click the „scan protocols“ Button. Now the protocols are scanned to detect a ECU.
