Summary of Contents for Victor 668
- Page 1 Инструкция по эксплуатации кабель-тестера VICTOR 668...
- Page 2 Cable tracker Operation Manual Thank you for using our product. In order to learn about the correct operating method, functions and inspection and maintenance essentials of the product and make the product rugged and durable, please read the manual carefully before using the product.
- Page 3 do not use it. 3. Do not use the product in electric storms, wet weather or thunderstorm weather. 4. Do not detect high-voltage cable lines (such as 220V power supply lines) with the product. 5. Do not use the product in a place with any combustible gas or much dust or vapor.
- Page 4 and metallic cables and connectors such as RJ11 connectors and R45 connectors. It is a necessary detection device for the persons taking work in fields including networks, telecommunication, broadcasting and TV, security protection, electric power, etc.
- Page 5 Safety instruction Warning...
- Page 6 Please read the manual carefully to avoid electric shocks, burns and other injuries. II. Technical indexes and specification Transmission signal distance: ＜200m Low voltage indication: Automatic low battery detection; on status of the low voltage indicator when the battery voltage is lower than the operating voltage Sampling frequency: 2.5 s/time Power source: 9V batteries, 006P Dimensions: 140 mm ×...
- Page 7 □ Network cable matching (RJ45) □ Telephone cable tracking (RJ11) □ Network cable tracking (RJ45) □ Power cable tracking (RJ11) □ Value and polarity of DC level □ Connectivity status and impedance of cable □ Switching between two frequencies during cable tracking IV.
- Page 8 convenient and can replace a network tester. The product can be easily used in dim places because of an LED lamp. The product is provided with a headset for the sake of easy use in noisy places. The product can prompt an undervoltage status of the batteries.
- Page 9 cable or telephone cable to the corresponding jack (such as RJ11 or RJ45) of the transmitter or connect a target metallic cable to the RJ11 jack via the standard accessory crocodile for RJ11 connector. 2) Hold the receiver and press the cable tracking start button.
- Page 10 The product can check the sequence, short or open circuit, correctness, reverse connection and crossing of each network cable. It can realize cable tracking when Ethernet switches, routers and PC terminals are in an on status. However, it should never be used for detecting live cables, particularly high-voltage cables.
- Page 11 b) Insert a local call telephone cable connector into the RJ11 jack of the transmitter. If the ‘Telephone’ function LED indicator is lit, it suggests that the telephone cable is normal, otherwise it suggests that the telephone cable has a fault. 2) Judge the unoccupied, ringing or off-hook status of an operating telephone cable;...
- Page 12 a) Press the power switch button of the transmitter and select the telephone function through the function selection button (the telephone function LED indicator will be lit); b) Insert the RJ11 plug of the crocodile clip for RJ11 plug into the RJ11 jack of the transmitter and clamp the detected telephone cable with the red clip and the black clip.
- Page 13 switch button of the transmitter and select the on-off function through the function selection button (the on- off function LED indicator will be lit). The transmitter will then begin to operate. Insert the RJ11 plug of the crocodile clip for RJ11 plug into the RJ11 jack of the transmitter and clamp the detected cable with the red clip and the black clip.
- Page 14 In the case of an undervoltage status (lower than 6V) of the batteries, the low voltage LED indicator on the receiver will be in yellow. VI. Product maintenance Clean the product surface at regular intervals with wet cloth and a little detergent rather than grinder or chemical solvent.
- Page 15 1. Replace the batteries. The manual is subject to change without notice. Content of the manual is believed correct. If you find any mistake or missing content, please contact us. We will not assume responsibility for the accidents and harms due to improper operation by users. Users should not regard the functions described in the manual as their causes for using the product for other purposes.
