Summary of Contents for MYUNGSAN MS850FHR
- Page 1 30p, 21 April, 2000 MYUNGSAN HYDRAULIC ROTATABLE PULVERIZER OPERATION AND PARTS MANUAL MYUNGSAN...
- Page 2 WARRANTY INFORMATION WARRANTY is provided as part of the Myungsan support program for customers who operate and maintain their equipment as described in this manual. Should the equipment be abused or modified to alter its performance beyond original specifications, the warranty will become void.
-
Page 3: Table Of Contents
CHAPTER 2. SPECIFICATIONS … … … … … … … … … … … … … … … … … … … ..9 CHAPTER 3. EXTERNAL DIMENSIONS … … … … … … … … … … … … … … … .10 3.1 MS850FHR 3.2 MS1000FHR 3.3 MS1300FHR... -
Page 4: Chapter 1. Precautions And Safety Symbols
CHAPTER 1. PRECAUTIONS AND SAFETY SYMBOLS 1.1 PRECAUTIONS The Myungsan Hydraulic Rotatable Pulverizer can operate safely and normally if it is operated in accordance with instruction given in this manual. Read this manual thoroughly before operation. If operator do not understand necessary instructions completely serious personal injury or equipment damage can occur. - Page 5 (10) Do not operate this pulverizer when you are under the influence of drug or alcohol. (11) Detach pulverizer from excavator during transport. (12) Observe the excavator manufacturer’s safety regulations.
-
Page 6: Safety Symbols
1.2 SAFETY SYMBOLS Your safety and the safety of others is a result of how you operate and maintain your equipment. Read and understand this manual and other safety information provided with the carrier machine. Carefully read all safety messages in this manual and on your equipment safety signs. -
Page 7: Label Locations
1.3 LABEL LOCATIONS ITEM DESCRIPTION GREASE DECAL- one at each grease fitting DANGER DECAL-1-one on front side of body DANGER DECAL-2-one on back side of body LOGO DECAL-one on front side of body MODEL DECAL-one on back side of body MODEL and SERIAL NUMBER plate-one on front side of top bracket WARNING DECAL –... - Page 8 ITEM 1 GREASE DECAL ITEM 2 DANGER –1 DECAL...
- Page 9 ITEM 3 DANGER-2 DECAL-2 ITEM 6 MODEL and SERIAL NUMBER PLATE ITEM 7 WARNING DECAL...
-
Page 10: Chapter 2. Specifications
CHAPTER 2. SPECIFICATIONS MODEL ITEM MS850FHR MS1000FHR MS1300FHR Cylinder Force (lb) 263,396 263,396 344,609 Metric (ton) Attachment Weight-Approx (lb) 4,829 6,804 9,219 Metric (kg) 2,200 3,100 4,200 Carrier Weight-Approx (lb) 39,509-61,459 61,459-87,799 87,799- Metric (ton) 18-28 28-40 153,648 40-60 Dimension... -
Page 11: Chapter 3. External Dimensions
CHAPTER 3. EXTERNAL DIMENSIONS Model Length(L) Width(W) Opening Width(O) MS850FHR (in) (mm) 2,296 1,200 MS1000FHR (in) (mm) 2,543 1,360 MS1300FHR (in) (mm) 3,200 1,480 1,100... -
Page 12: Chapter 4. Installation
CHAPTER 4. INSTALLATION 4.1 GENERAL VIEW Name Hydraulic Pump Oil Tank Main Control Valve Directional Control Valve for Cylinder Directional Control Valve for Rotating Motor Pedal Switch Electric Fuse... -
Page 13: Hydraulic Circuit
4.2 HYDRAULIC CIRCUIT... -
Page 14: Pulverizer Mounting Procedure
4.3 PULVERIZER MOUNTING PROCEDURE 1. Place the pulverizer on the ground(or wood block) with blocking to keep the pulverizer level for installation. 2. Remove the bucket or other attachment following the manufacturer’s recommended procedure. Be careful not to contaminate the hydraulic system by plugging the hydraulic hoses. 3. -
Page 15: Pulverizer Removal Procedure
4.4 PULVERIZER REMOVAL PROCEDURE 1. Position the pulverizer under the boom of the excavator. Trapped hydraulic pressure may be present after base machine is turned off. Extreme caution must be taken when removing pulverizer hydraulic hoses or possible injury or death could result. -
Page 16: Chapter 5. Operation And Maintenance
CHAPTER 5. OPERATION AND MAINTENANCE 5.1 PRECAUTIONS FOR SAFE OPERATION (1) Check the excavator position is stable. (2) Do not use pulverizer like a lever. - Page 17 (3) Do not pull or push object with pulverizer when cylinder is acting. (4) Do not hit the pulverizer against the object.
- Page 18 (5) Inadequate operation can cause damage to the cylinder rod. (6) Operate carefully not to hit the excavator with the pulverizer...
-
Page 19: Maintenance
5.2 MAINTENANCE Inspection Items Check Points and Remedy 1. Bolts, Nuts, Snap-Ring, etc -Looseness, damage, missing à Tighten, replace -Damage on the surface of cylinder rod. 2. Cylinder-Rod à Surface finishing or replace -Oil leakage, or bolt looseness 3. Center-Joint à... - Page 20 ROTATOR MAINTENANCE The rotator is capable of 360 degree continuous rotations for easy, accurate crushing at all angles. The rotator is to be used only as a positioning features, not as a means of bending or breaking material. Use of he rotation feature for any other purpose may damage the rotation components and may compromise the attachment’s warranty.
- Page 21 For Operation Below For Operation Above Maker Trade Name C (32 F), & For C (32 storage AMOCO Rycon CHEVRON Dura Lith EXXON Lidok MOBIL Mobilux SHELL Alvania EPR0 SOHIO Bearing Guard Prestige 740EP 742EP TEXACO Multifak UNION Unoba HYDRAULIC REQUIREMENTS The rotating attachment requires an auxiliary hydraulic circuit in order to operate the rotator.
- Page 22 PULVERIZER STORAGE 1. Block the pulverizer up off the ground using wood blocking. 2. Grease the pins and machined bores of the mounting bracket of the attachment. Then apply a generous amount of grease to shear blades, cylinder rod and all other exposed and unpainted surfaces.
-
Page 23: Chapter 6. Trouble Cause And Remedy
CHAPTER 6. TROUBLE CAUSE AND REMEDY Trouble Cause Remedy Phenomena à Check battery or electric 1.1 Electric shortage. wire. Connect wire. à Repair solenoid spool or 1.2 Sticking in solenoid valve. replace with new one. à Check the piping(turn on 1. -
Page 24: Chapter 7. Exploded View And Parts List
CHAPTER 7. EXPLODED VIEW AND PARTS LIST 7.1 EXPLODED VIEW... -
Page 25: Parts List
7.2 PARTS LIST 7.2.1 MS850FHR Name Part No Quantity Remark BODY MF0300100 TOOTH MF0300200 CYLINDER MF0300300 SLEW-RING MF0300400 MF0300500 CENTER JOINT MF0300600 MF0300700 MOTOR MF0300800 PINION MF0300900 BUSH-B3 MF0301000 1 x 2 PIN-BODY MF0301100 PIN-CYLINDER MF0301200 PLUG-B MF0301300 1 x 2... - Page 26 Name Part No Quantity Remark O-RING MF0304100 1 x 3 BACKUP RING MF0304200 1 x 4 For P90 DUST SEAL MF0304300 LBI180 WEAR RING MF0304400 1 x 3 ROD PACKING MF0304500 ISI180 BACKUP RING MF0304600 For ISI180 O-RING MF0304700 G210 BACKUP RING MF0304800 For G210...
- Page 27 7.2.2 MS1000FHR Name Part No Quantity Remark BODY MF0400100 TOOTH MF0400200 CYLINDER MF0400300 SLEW-RING MF0400400 MF0400500 CENTER JOINT MF0400600 MF0400700 MOTOR MF0400800 PINION MF0400900 BUSH-B3 MF0401000 1 x 2 PIN-BODY MF0401100 PIN-CYLINDER MF0401200 PLUG-B MF0401300 1 x 2 PLUG-C MF0401400 BUSH-L2 MF0401500 2 x 2...
- Page 28 Name Part No Quantity Remark O-RING MF0404100 1 x 3 BACKUP RING MF0404200 1 x 4 For P90 DUST SEAL MF0404300 LBI 180 WEAR RING MF0404400 1 x 3 ROD PACKING MF0404500 ISI 180 BACKUP RING MF0404600 For ISI 180 O-RING MF0404700 G210...
- Page 29 7.2.2 MS1300FHR Name Part No Quantity Remark BODY MF0500100 TOOTH MF0500200 CYLINDER MF0500300 SLEW-RING MF0500400 MF0500500 CENTER JOINT MF0500600 MF0500700 MOTOR MF0500800 PINION MF0500900 BUSH-B3 MF0501000 1 x 2 PIN-BODY MF0501100 PIN-CYLINDER MF0501200 PLUG-B MF0501300 1 x 2 PLUG-C MF0501400 BUSH-L2 MF0501500 2 x 2...
- Page 30 Name Part No Quantity Remark O-RING MF0504100 1 x 3 BACKUP RING MF0504200 1 x 4 DUST SEAL MF0504300 WEAR RING MF0504400 1 x 3 ROD PACKING MF0504500 BACKUP RING MF0504600 O-RING MF0504700 BACKUP RING MF0504800 O-RING MF0504900 BACKUP RING MF0505000 PISTON PACKING MF0505100...
