Osstem Implant K3 Installation Manual

Unit chair
Hide thumbs
Table of Contents

Advertisement

Quick Links

K3 Unit Chair Installation
Osstem Implant
Technical Support Division

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K3 and is the answer not in the manual?

Questions and answers

Related Manuals for Osstem Implant K3

Summary of Contents for Osstem Implant K3

  • Page 1 K3 Unit Chair Installation Osstem Implant Technical Support Division...
  • Page 2 K3 Unit Chair Installation (Mechanical) Osstem Implant...
  • Page 3 Contents K3 installation Checklist Ⅰ Select installation location Ⅱ K3 UNIT CHAIR Installation Ⅲ Pipeline installation Ⅳ Air / Water Line Diagram Ⅴ...
  • Page 4 K3 Installation Ⅰ Checklist...
  • Page 5 Ⅰ K3 Installation Checklist Packing Box Components 1. CHAIR BOX 2. UNIT BOX 3. TABLE BOX 4. LIGHT ARM BOX 5. LIGHT HEAD BOX 6. SEAT BOX 7. DOCTOR STOOL BOX...
  • Page 6 Ⅰ K3 Installation Checklist Checklist before Installation • Check the product transportation route. • The product must be transported in a packed state. If packing materials need to be removed before transportation, soft materials must be used to prevent damage to the product.
  • Page 7 Ⅱ Select installation location...
  • Page 8 2.5m at least • Distance from piping to the spittoon must be within • Sufficient space must be secured for repair and maintenance • Support structure must be able to withstand the weight of equipment K3 Unit Chair Size §...
  • Page 9 K3 UNIT CHAIR Installation Ⅲ...
  • Page 10 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #1 < Figure 01 > Wall 1. Install the base plate Piping position Large R size Narrow gaps Check the direction to place the main plate (A) on...
  • Page 11 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #2 < Figure 03 > 3. Install the chair assembly As shown in <Figure 03>, place the chair assembly (B) on the main plate (A), align the bolt hole positions and fasten the fixing bolts and level adjustment bolts, referring to <Figure 02>.
  • Page 12 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #3 < Figure 05 > 5. Install backrest bracket As shown in <Figure 05>, assemble the backrest bracket (D) to the backrest support ①. Use a Phillips screwdriver 6.
  • Page 13 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #4 < Figure 07 > 7. Install backrest cover Referring to <Figure 07>, align the heads of 4 bolts for the backrest cover (F) with the holes (b) of the backrest seat (E), and push the bolts down to insert them into the holes.
  • Page 14 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #5 < Figure 09 > 9. Install seat As shown in <Figure 09>, push the seat assembly (H) in the backrest direction to set the position to mount the seat assembly.
  • Page 15 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #6 < Figure 11 > 11. Remove the main power cable As shown <Figure 11>, remove the main power cable located in the chair assembly. 12. Assemble power switch <...
  • Page 16 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #7 < Figure 13 > 13. Assemble main power cable As shown in <Figure 13>, connect the connector. 14. Assemble power switch < Figure 14 > As shown in <Figure 14>, place the base front cover (J) on the base plate and fasten with bolts on both sides.
  • Page 17 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation procedures #8 < Figure 15 > 15. Install motor cover As shown in <Figure 15>, mount a hook (C) located on the front side of the motor cover (K) aligning with the groove on the base front cover (J).
  • Page 18 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation precautions #1 1. Align the backrest cover with the center of the headrest Good Example Bad Example Regular gaps Irregular gaps 2. Perform an armrest operating test to check whether there is any interference with...
  • Page 19 Ⅲ K3 UNIT CHAIR Installation 『CHAIR Installation』 CHAIR INSTALLATION § Installation precautions #2 3. Chair levelness adjustment After installing the unit chair, check the levelness using a level gauge, and balance the unit chair using the levelness adjustment bolt shown in <Figure 01>.
  • Page 20 Ⅲ K3 UNIT CHAIR Installation 『UNIT Installation』 UNIT INSTALLATION § Installation procedures #1 < Figure 01 > 1. Remove Unit Base Cover_R Unfasten 2 bolts as shown in <Figure 01> and remove the Unit Base Cover_R (A). Use a Phillips screwdriver 2.
  • Page 21 Ⅲ K3 UNIT CHAIR Installation 『UNIT Installation』 UNIT INSTALLATION § Installation procedures #2 < Figure 03 > 3 Fasten levelness adjustment bolt As shown in <Figure 03>, temporarily fasten the levelness adjustment bolt for the unit to the Main Plate (C).
  • Page 22 Ⅲ K3 UNIT CHAIR Installation 『UNIT Installation』 UNIT INSTALLATION § Installation procedures #3 < Figure 05 > 5. Remove bolt cap As shown in <Figure 05>, remove the rubber cap mounted on Unit Base Cover_L. 6. Remove fixing bolt < Figure 06 >...
  • Page 23 Ⅲ K3 UNIT CHAIR Installation 『UNIT Installation』 UNIT INSTALLATION § Installation procedures #4 < Figure 07 > 7. Fix Unit Assembly As shown in <Figure 07>, fasten the bolt fixing the Main Plate (C) and the Unit Assembly (A) and tightly fasten the bolt that was temporarily fastened in Step 4.
  • Page 24 Ⅲ K3 UNIT CHAIR Installation 『UNIT Installation』 UNIT INSTALLATION § Installation procedures #5 < Figure 09 > 9. Fix Assist Table Assembly As shown in <Figure 09>, fasten Unit Assembly (E) and Assist Table Assembly (F) using bolts. Use a Phillips screwdriver 10.
  • Page 25 Ⅲ K3 UNIT CHAIR Installation 『UNIT Installation』 UNIT INSTALLATION § Installation procedures #6 < Figure 11 > 11. Assemble Back Low Cover As shown in <Figure 11>, align the Back Lower Cover (B) with the Assembly Ball and push it in the arrow direction to put the cover in ※...
  • Page 26 Ⅲ K3 UNIT CHAIR Installation 『UNIT Installation』 UNIT INSTALLATION § Installation precautions 1. How to move Unit Assembly Dangerous point Safety When moving Unit Assembly, you must when lift up to move Section grab the safety point (position #2 and 3).
  • Page 27 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation procedures #1 < Figure 01 > 1. Install Large Arm Assembly As shown in <Figure 01>, level off the Large Arm Assembly (A) and put it in Unit Assembly ① in the vertical direction.
  • Page 28 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation procedures #2 < Figure 03 > 3. Insert Wire in Doctor Table Assembly As shown in <Figure 03>, hold the Doctor Table Assembly (B) and pass the wire through the inside of Large Arm (C) to insert it inside the unit.
  • Page 29 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation procedures #3 < Figure 05 > 5. Assemble Sub Table As shown in <Figure 05>, fasten Sub Table (E) to Sub Table Bar (F) with bolts. Use a Phillips screwdriver 6.
  • Page 30 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation procedures #4 < Figure 07 > 7. Install Chart Holder As shown in <Figure 07>, align and insert the Chart Holder (I) in the holes on Upper Table Block (H).
  • Page 31 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation procedures #5 < Figure 09 > 9. Assemble Mouse Pad As shown in <Figure 09>,insert the Mouse Pad (J) into the side of Doctor Table and fasten with bolts.
  • Page 32 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation procedures #6 < Figure 11 > 11. Mount Stainless Tray As shown in <Figure 11>, mount Stainless Tray (L) on the Sub Table (E).
  • Page 33 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation precautions #1 1. Level off Doctor Table As shown in the figure, remove the Table Cover. Adjust the wrench bolts shown in Figure "A" and "B“ and level off the Doctor Table.
  • Page 34 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation precautions #2 3. Balance Arm Tension Fixing Device Turn the Balance Arm Knob shown in Figure "D" counter- clockwise to lock it, and the load will be applied to the tension adjustment device, which leads to an increase in the fixing force of the Balance Arm.
  • Page 35 Ⅲ K3 UNIT CHAIR Installation 『TABLE Installation』 DOCTOR TABLE INSTALLATION § Installation precautions #3 5. How to Adjust Water Volume for the Balance Arm Water volume adjustment valve is placed on the bottom right of the Doctor Table. Turn each valve clockwise to decrease the water volume;...
  • Page 36 Ⅲ K3 UNIT CHAIR Installation 『MONITOR ARM Installation』 MONITOR ARM INSTALLATION § Installation procedures #1 < Figure 01 > 1. Install Light Pole As shown in <Figure 01>, level off the Large Arm (A) and insert the Light Pole (B) in the vertical direction.
  • Page 37 Ⅲ K3 UNIT CHAIR Installation 『MONITOR ARM Installation』 MONITOR ARM INSTALLATION § Installation procedures #2 < Figure 03 > 3. Install Monitor Arm Support As shown in <Figure 03>, align Support_Left (C) and Support_Right (D) on Light Pole (B) and fasten with bolts.
  • Page 38 Ⅲ K3 UNIT CHAIR Installation 『MONITOR ARM Installation』 MONITOR ARM INSTALLATION § Installation procedures #3 < Figure 05 > 5. Install Monitor Arm Assembly As shown in <Figure 05>, align and put the Monitor Arm Assembly (F) in the bolt holes on Support_Left (C) and Support_Right (D).
  • Page 39 Ⅲ K3 UNIT CHAIR Installation 『MONITOR ARM Installation』 MONITOR ARM INSTALLATION § Installation procedures #4 < Figure 07 > 7. Insert Monitor Arm Wire As shown in <Figure 07>, pass the wire of Monitor Arm Assembly (F) through the Light Pole (B) to insert it into the unit.
  • Page 40 Ⅲ K3 UNIT CHAIR Installation 『MONITOR ARM Installation』 MONITOR ARM INSTALLATION § Installation precautions 1. Installation direction of monitor arm < Figure 01 > Spittoon Monitor Arm When installing the monitor arm, install it at an angle of 30˚ (or 5 o'clock) when looking straight at the front surface of the Spittoon.
  • Page 41 Ⅲ K3 UNIT CHAIR Installation 『DENTAL LIGHT Installation』 DENTAL LIGHT INSTALLATION § Installation procedures < Figure 01 > 1. Insert Wire in Light Arm Assembly As shown in <Figure 10>, pass the wire of Light Arm Assembly through the Light Pole ① to insert it in the unit.
  • Page 42 Ⅲ K3 UNIT CHAIR Installation 『 HANARO CONSOLE Installation』 HANARO CONSOLE INSTALLATION § Installation procedures #1 < Figure 01 > 1. Assemble Main Body As shown in <Figure 01>, put the Support Insert (B) in the Main Body (A). 2. Assemble Pole Support <...
  • Page 43 Ⅲ K3 UNIT CHAIR Installation 『 HANARO CONSOLE Installation』 HANARO CONSOLE INSTALLATION § Installation procedures #2 < Figure 03 > 3. Install Main Body As shown in <Figure 03>, fasten Main Body (A) and Pole Support (C) to Light Pole ① using bolts.
  • Page 44 Ⅲ K3 UNIT CHAIR Installation 『 HANARO CONSOLE Installation』 HANARO CONSOLE INSTALLATION § Installation procedures #3 < Figure 05 > 5. Assemble Side Table As shown in <Figure 05>, put the Side Table (E) in the side groove on the Main Body (A) in the direction indicated by the arrow.
  • Page 45 Ⅲ K3 UNIT CHAIR Installation 『 HANARO CONSOLE Installation』 HANARO CONSOLE INSTALLATION § Installation procedures #4 < Figure 07 > 7. Assemble Main Top Body Right As shown in <Figure 07>, put Main Top Body Right (G) over the Main Body (A).
  • Page 46 Ⅲ K3 UNIT CHAIR Installation 『 HANARO CONSOLE Installation』 HANARO CONSOLE INSTALLATION § Installation precautions 1. Support Insert mounting position Good Good Mounting support part Mounting support part (main body side) (pole side) 2. How to assemble the Cup Ejector...
  • Page 47 Pipeline installation Ⅳ...
  • Page 48 Ⅳ Install pipelines How to Install Pipe A: Connect the spittoon drain line to the floor pipe. B: Connect the suction drain line to the CVS. (For air suction system, connect the line to the floor pipe) C: Connect to the water input line. D: Connect the air input to the compressor.
  • Page 49 Air/Water Line Diagram Ⅴ...
  • Page 50 Ⅴ Air / Water Line Diagram Basic System...
  • Page 51 Ⅴ Air / Water Line Diagram Air Suction System...
  • Page 52 Ⅴ Air / Water Line Diagram Water Sanitation System...
  • Page 53 Thank you...
