Juna JMC-03 Installation Manual

Tv dvb-t for car

JMC-03

TV DVB-T for CAR

INSTALLATION MANUAL

1. INTRODUCTION ...................................................................

2. RECOMMENDATIONS .........................................................

3. SCHEME OF CONNECTIONS .............................................

4. BASIC TECHNICAL PARAMETERS ....................................

5. ELEMENTS SET ....................................................................

JuNa

PPHU

Manufacturer

ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND

Model:

JMC-03_V2.2_MMI_2G/3G

Content

Table of Contents

Need help?

Do you have a question about the JMC-03 and is the answer not in the manual?

Page 1 JMC-03 Model: JMC-03_V2.2_MMI_2G/3G TV DVB-T for CAR INSTALLATION MANUAL Content 1. INTRODUCTION ..............2. RECOMMENDATIONS ............3. SCHEME OF CONNECTIONS ..........4. BASIC TECHNICAL PARAMETERS ........5. ELEMENTS SET ..............JuNa PPHU Manufacturer ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND...
Page 2 Module is dedicated for AUDI cars equipped with multimedia system MMI 3G/3G+ . After mounting, JMC-03 is recognized as digital TV tuner by factory mounted MMI system and added to the list of supported devices in the car This solution allows to control DVB-T tuner through existing MMI system in the car.
Page 3 In the interest of high quality and development of our products, JUNA Electronics reserves the right to make technical changes. In the case of a warranty claim, the device should be sent back to the seller in original packaging with a detailed description of the problem with attached purchase invoice.
Page 4 4. Connect second plug of ﬁber optic splitter to socket in MMI 3G in place of disconnected ﬁber optic plug. Point 5. Connect video IN signal socket MMI unit with JMC-03 device using proper cable. 6. Connect antennas ANT.1 and ANT.2 to antennas sockets.
Page 5 - Metal 7. Dimensions - 93mm x 143mm x 28mm 8. Weight - 371g 5. ELEMENTS SET 1. Control unit - JMC-03 2. Connection cable - W-TV101a 3. Connection cable Video - K-F101a/b 4. Fiber optic splitter MOST - K-SW101 5.
