Eurotops MA565 Manual

MA565/ MG81001-A
Please read the instruction manual carefully before using the product.
A PRODUCT FEATURES
2 swivelling and adjustable LED lamps
4 adjustable and interchangeable magnifying lenses: x1.2, x1.8, x2.5, x3.5
Adjustable soft plastic headband for handsfree work
Suitable for some hobbies and crafts operated at a dim or dark place: fishing, reading, gardening, sewing,
embroidery, carving, handcraft, stamp collection, drawing, assembling small fittings, repairing your car or
computer at night, etc.
Powered by 2 AAA batteries (1.5V each)
B PRODUCT DESCRIPTION
Fig.1
C HOW TO USE THE LIGHT?
In order to turn on or off the light, push the switch (3 - Fig.1) marked with ON (downwards) and OFF (upwards).
The angle of LED light can also be adjusted as follows:
Fig. 2
D HOW TO CHANGE THE BATTERY?
Fig.3
Fig.4
E METHOD FOR INSTALLING AND REMOVING THE LENS
A) Installing the lens:
1. Before proceeding with installing the lens, swivel the reversed U type of groove to the upward position
(the lens should be installed in a bounce position as figure 5).
2. Put the lens upside down on soft paper or cloth in order to protect it from fingerprints.
3. Before any installation, make sure to put the convex side of lens outward (Fig.6) and put the flat side
(Fig.7) towards your eyes (the side through which can read or see is the flat side).
4. Install the lens by ensuring to keep the lens parallel to groove, and press. Brackets of lens should be
inserted into the plug-in holes on a straight line. If they are not parallel when installing, the upside part of
the lens can be damaged. When the brackets are correctly inserted, you should hear a click.
5. According to the usage you need, the bracket can be rotated upward or downward for 45 degree.
Note: you can also overlap two lenses, but pay attention to put the higher magnification in the first
position and the lower magnification just behind the higher magnification, in the second position.
2 LED HEADBAND TELESCOPES
1. Plug-in hole for lens
2. Lens
3. ON/ OFF switch for light
4. Adjusting screw
5. Head band
6. Fixing band
7. Light
Referring to the figure
(2) on the left, please
adjust the light by
moving the black LED
light UP and DOWN
with your hand.
Put the headband magnifier upside down in
order to locate the battery compartment.
Put your thumb in front of the black tab of
the battery cover with symbol and word
OPEN. Press on it firmly till it springs out
and open. You will hear a click confirming
that the battery cover is opened.
Install 2 AAA or LR03 battery type. Make
sure to sure to follow the + and - polarities
marked inside the battery compartment.
Then, close the battery cover by putting your
finger on the tab and press on it.
You can turn the light
left or right
degree if you need.
Fig. 3
for 25
