TQLink AW920 User Manual

Mifi 3g wireless router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MiFi 3G Wireless Router

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW920 and is the answer not in the manual?

Questions and answers

Summary of Contents for TQLink AW920

  • Page 1 MiFi 3G Wireless Router...

  • Page 2: Warm Prompt

    Thank you for purchasing the 3G wireless router Explanation: s standard, the pictures are just for reference. About the detailed information, please inquire your operator. to 32GB. d other users using your MiFi. Warm Prompt: at other states MiFi can also charge for other devices.
  • Page 3 Introduction of MiFi 1.Micro SD Card Indicator Light 2.LAN Indicator Light 3.3G Indicator Light 4.Power Bank Indicator Light 6.Brand LOGO 7.Select Button or Data Indicator Light 8.LAN/WAN Port 9.Micro SD Card Slot 11.Power Switch 12.Reset 13.USB Port only supply power for other device 14.Micro-USB Charging Port...

  • Page 4: Device State

    Device state Indicator Light Status Micro SD Card Indicator Light LAN Indicator Light 3G Indicator Light Power Bank Indicator Light Battery Indicator Light Charge Indicator Light The lights go out:Charge Complete work Data Indicator Light Explanation: The state of SD card, LAN , 3G , Power Bank is switched by pressing down the Select Button.

  • Page 5: Power Bank

    Install the Smart card and Micro SD card According to the direction of graphic insert the Micro SD card and smart card into corresponding card slot. Note:Please don't plug or unplug the smart card and SD card when device working to avoid the data lost or damage. Turn ON/OFF Turn on:Turn the power switch to 'ON' Turn off:Turn the power switch to 'OFF'...
  • Page 6 Turn 3G to WiFi Step one：Open the MiFi blue，you can access to the internet. Step two：Establish a WiFi connection (Connect Computer for example) 1.Choose Start=>Control panel=>Network Connections=>Wireless Network connection. Explanation:Before establishing a WiFi connection, it must ensured that the computer has been equipped with a wireless card. If the computer indicates the existence of wireless networks, then the wireless card can be used.
  • Page 7 Turn wired network to WiFi the data indicator light is always blue，you can access to the internet. Connection procedure above. Login management page 1. Confirm the connection of MiFi with WiFi is good. 2. Open the browser, enter ‘http://192.168.43.1’ in the address field or just enter ‘192.168.43.1’...
  • Page 8 Modify the SSID and password 1．Choose Basic => Wizard 2．Enter the SSID and password that you need 3．Click 'apply' Static IP 1．Choose Basic => Wizard 2．Select Static IP connection type 3．Enter IP,Subnet Mast,Gateway. 4．Click 'apply' Explanation: Static IP, DHCP, PPPoE , should ensure that the state has switched to LAN, and the system mode must be the gateway mode.

  • Page 9: Wireless Mac Filter

    PPPoE 1．Choose Basic => Wizard 2．Select PPPoE connection type 3．Enter user name and password 4．Click 'apply' Explanation:If in the condition of LAN you can't get to the Internet, please select the correct connection type according to the actual condition. Wireless Macfilter 1．Choose Wireless =>...

  • Page 10: Storage Management

    Wireless Network to WIFI 1．Choose Advaced => Route => SYS Mode 2．Select the AP client mode .Click 'apply' 3．Search the AP and enter the password.Click 'apply' Explanation:The MiFi can act as a Wireless Repeater to turn Wireless network to WiFi .Please ensure that the state has switched to the LAN and without the NetworkCable before setting.
  • Page 11 Android Mobile Phone/Panel Accesses SD via Wifi 1．Switch to the state of SD card. 2．Open the ES file explorer , Click “LAN”menu,then “New” and then “Sever” and input position. The IP address of the router 3．After settings are finished, “192.168.43.1” can be found in the share list.Click it and open “Home” can accesses SD.
  • Page 12 Explanation: If your android device is not installed ES file browser, please download and install.If you can not access the SD card, check the samba fuction is turned on.

  • Page 13: Restore The Factory Settings

    Charge the MiFi If the battery has not been used for a long time, please charge it to saturation state before use. Restore the factory Settings If you forget the modified password and SSID, please take the following methods to restore WiFi default values: T button for 3 seconds.Just wait for a moment, the MiFi will restart.
  • Page 14 1、Forget the login password so it can not enter MiFi configuration page. Press "RESET" button for 3 seconds, then you can restore the factory settings. 2、The IP address conflict after MiFi connection. Please confirm there are not the same IP devices in the LAN. 3、...
  • Page 15 6、For A which backward compatible CDMA1x. For using a faster network services, 3G settings checked by def w, I suggest you try to remove that option, choose Basic ==> W click "Apply." Explanation: if you choose “Auto you can choose “Manual Config” then input your APN and other relevant parameters.
  • Page 16 Made in china...
