- Page 1 ` User Manual and Installation Guide Proxy Mobile Reader Pro www.proxy.com | support@proxy.com Last updated: February 10, 2020 ...
- Page 2 | 2 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install...
-
Page 3: Table Of Contents
Install Troubleshooting 18 Warranty 19 | 3 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 4: Introduction
Reader Functionality Mobile Reader Pro is a physical access control wireless mobile credential and smart card reader that can read HF / LF contactless credentials conforming to the following standards: ISO 14443 A & B as well as wireless credentials over Bluetooth Low Energy (BLE). The reader can interface with an access ... -
Page 5: Mobile Reader Pro Wallbox Main Housing
Dimension in millimeters (mm) & inches (in) | 5 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 6: Mobile Reader Pro Mullion Main Housing
Dimension in millimeters (mm) & inches (in) | 6 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 7: Product Specifications
This device has been tested and meets applicable limits for Radio Frequency (RF) exposure. | 7 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 8: Installation Details
100-ohm characteristic impedance (option: Category 5 shielded twisted pair (STP)). | 8 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 9: Wiring Information
| 9 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 10: Mounting The Mobile Reader Pro
Location of mounting holes on the wall (Wallbox) | 1 0 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 11: Location Of Mounting Holes On The Wall (Mullion)
Connect the wires as per the Table in Section 5.3.1 ● Mobile Reader Pro Wallbox Wall Plate is to be secured onto the wall using the Screws ● Mobile Reader Pro Wallbox Main Housing can be installed onto Wall Plate ... -
Page 12: Wiring Diagrams
Powered by Access Control Panel Powered by External Power Supply | 1 2 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 13: Wiring Recommendations
| 1 3 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 14: Certifications
| 1 4 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... - Page 15 This equipment should be installed and operated with a minimum distance of 20 cm between the radiator & your body. | 1 5 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install...
- Page 16 (dBm) Band / Mode LE GFSK Bluetooth 1.0 Hereby, Proxy, Inc., declares that the radio equipment type Mobile Reader Pro is in compliance with Directive 2014/53/EU. | 1 6 User Manual and Installation Guide: Proxy Mobile Reader Pro ...
-
Page 17: Ul294
Standby Power: Level I ● | 1 7 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 18: Install Troubleshooting
| 1 8 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install... -
Page 19: Warranty
For warranty information, visit this link: h ttps://www.proxy.com/legal | 1 9 User Manual and Installation Guide: Proxy Mobile Reader Pro This document may have been updated since printing — for the latest, please visit h ttps://proxy.com/s/pro-install...
