TELEDYNE DETCON MODEL SW-A2V2-DV2
Hazardous Duty Class 1 Division 2 Multi-tone Alarm Station
Operator's Installation and Instruction Manual
Teledyne Detcon, Inc.
4055 Technology Forest Blvd. Suite 100
The Woodlands, Texas 77381
Ph.713.559.9200 / Fax 713.893.6729
www.teledynegasandflamedetection.com
December 3, 2019 • Document # 4572 • Revision 0.3
Advertisement
Table of Contents
Summary of Contents for Teledyne Detcon SW-A2V2-DV2
- Page 1 TELEDYNE DETCON MODEL SW-A2V2-DV2 Hazardous Duty Class 1 Division 2 Multi-tone Alarm Station Operator’s Installation and Instruction Manual Teledyne Detcon, Inc. 4055 Technology Forest Blvd. Suite 100 The Woodlands, Texas 77381 Ph.713.559.9200 / Fax 713.893.6729 www.teledynegasandflamedetection.com December 3, 2019 • Document # 4572 • Revision 0.3...
- Page 2 SW-A2V2-DV2 This page left intentionally blank SW-A2V2-DV2 Instruction Manual...
-
Page 3: Table Of Contents
Figure 5 Battery Pack ............................3 Figure 6 Quad Battery Charger ..........................4 Figure 7 Dimensional ............................5 Figure 8 Unit Wiring ............................6 Table 1 Strobe Patterns…………………………………………………………………………………………..7 Figure 9 Flash Pattern Rate Configuration………………………………………………………………………7 Table 2 Sound Signals……………………………………………………………………………………….…..8 SW-A2V2-DV2 Instruction Manual... - Page 4 SW-A2V2-DV2 This page left intentionally blank Shipping Address: 4055 Technology Forest Blvd. Suite 100, The Woodlands Texas 77381 Mailing Address: P.O. Box 8067, The Woodlands Texas 77387-8067 Phone: 713.559.9200 • Fax: 713.893.6729 • www.teledynegasandflamedetection.com SW-A2V2-DV2 Instruction Manual...
-
Page 5: Description
SW-A2V2-DV2 1.0 Description The Teledyne Detcon SW-A2V2-DV2 Alarm Stations are wireless, battery powered alarm stations with a two Strobes and a Horn that can provide 2 of 32 possible alarm tones. The unit is designed for installation and use in corrosive work environments. -
Page 6: Strobe
The Horn is capable of producing up to 125dB @ 1m output dependent upon the tone settings (refer to the “Sound Signals” Table). Figure 4 Horn SW-A2V2-DV2 Instruction Manual Rev. 1.4 Page 2 of 11... -
Page 7: Smart Battery Pack
The battery packs are designed to plug into an 8-pin Beau connector on the Terminal Board that the sensor is connected to. The battery Pack and Terminal Board are housed and sealed in Teledyne Detcon’s Class I Div 1 Aluminum Condulet to protect them from exposure to outside elements. Operating periods before recharge will vary based on alarm usage but can be as long as 5 months for the 12V 2900mAh battery pack. -
Page 8: Rxt Wireless Transceiver
1.5 RXT Wireless Transceiver The wireless function of the alarm station is made possible by Teledyne Detcon’s RXT series wireless transceivers. These transceivers transmit signal data such as analog 4-20mA DC or serial Modbus™ and can support up to 32 devices. -
Page 9: Installation
The unit will power up and begin normal operation. Replace the cover on the junction Boxes and insure that the covers are completely screwed down and secured by the cap-head screw. SW-A2V2-DV2 Instruction Manual Rev. 1.4... -
Page 10: Figure 8 Unit Wiring
CAUTION: Explosion Hazard – DO NOT disconnect while the circuit is live or unless the area is free of ignitable concentrations. CAUTION: Explosion Hazard – DO NOT connect or disconnect when energized. SW-A2V2-DV2 Instruction Manual Rev. 1.4 Page 6 of 11... -
Page 11: Operation
SW-A2V2-DV2 3.0 Operation The SW-A2V2-DV2 Wireless Alarm Stations provide two strobes and a dual tone alarm horn. The wireless alarm station is set to respond to alarms from the controlling unit. The controller/wireless network has independent control over the strobes and the Horns, and they will be activated when the appropriate alarm is activated. -
Page 12: Horn
26 3 2850Hz pulses 0.5on/0.5off, 1.5 off 00110 Int. 3100 Hz 0.32s on / 0.68s off 00101 00100 Spare/Customer Tone 00011 Spare/Customer Tone 00010 Spare/Customer Tone 00001 Spare/Customer Tone 00000 Spare/Customer Tone SW-A2V2-DV2 Instruction Manual Rev. 1.4 Page 8 of 11... -
Page 13: Service And Maintenance
CAUTION: Explosion Hazard – Batteries must ONLY be changed in an area free of ignitable concentrations. CAUTION: Explosion Hazard – Batteries must ONLY be recharged in an area free of ignitable concentrations. SW-A2V2-DV2 Instruction Manual Rev. 1.4 Page 9 of 11... -
Page 14: Parts List
Up to 125dB(A) @ 1 meter (Tone dependent) Duty Cycle Not rated for continuous duty (5-minute duty cycle) Electrical Classification: Class I Division 2 Groups C, D T4 Tamb -20°C to +40°C SW-A2V2-DV2 Instruction Manual Rev. 1.4 Page 10 of 11... -
Page 15: Warranty
SW-A2V2-DV2 7.0 Warranty Teledyne Detcon Inc., as manufacturer, warrants under intended normal use each new SW-A2V2-DV2 Alarm station to be free from defects in material and workmanship for a period of one year. The warranty period begins from the date of shipment to the original purchaser and ends one year thereafter. All warranties and service policies are FOB the Detcon Inc.
