Page 2
ROTOR BLADE IMPORTANT! The paddle blades, located on the balance rings inside the chopper, must be installed in the direction shown (A). The straight edge of the blade cuts the air while the paddle trails behind & pushes the air. 1.
Page 3
KIT CONTENTS ITEM NAME ITEM DESCRIPTION AGCO CHOPPER ASSY SHIELD SHEILD C62 8680 DRIVE DEFL DEFLECTOR STRAW REAR BOX AGCO 8680 COMP BOX 14 x 24 x 8.5d HARDWARE BAG AGCO MAV STOP AGCO STR DOOR LT STOP AGCO STR DOOR RT BRACKET DRIVE SHIELD INSTAL MANUAL GAS SPRING...
4. Remove bottom piece of the rear wall straw deflector (E) by drilling out the rivets and removing 2 lower bolts (G). Replace straw deflector with Redekop straw deflector and bolt in place using existing welded on nuts (F) in upper piece and reuse 2 lower bolts.
Page 5
Raise chopper to the combine using a fork lift or front end loader (B) from the back. 2. Mount Redekop chopper in place using original chopper holes. Use: (See Appendix 1 Hardware Definitions) 8 - Bolt Flg M12 X 25L 8 - Nut Flg M12 3.
Page 6
Speed Sensor 1. Re-install speed sensor pickup lug onto Redekop Straw chopper shaft. Mount Speed sensor using the top two M12 bearing nuts. 2. Re-install the factory cover over the speedsensor. Straw Door Stops 1. With straw door in chopping position, bolt the straw door stops onto the chopper wall, using the door as a locator.
Page 7
Shield Installation 1. Re-install factory drive sheave and belt. 2. Install Redekop Drive shield. Bolt Redekop shield bracket (B) onto side of chopper to stabilize shield using round head bolt. Use: 1 - Bolt RH M8 X 20L 1 - Nut M8 3.
WARRANTY Redekop Manufacturing Co., hereinafter referred to as “Manufacturer”, warrants each new Redekop Upgrade sold by the Manufacturer to be free from defects in ma- terial and workmanship, under normal use and service, for a period of one (1) year after the date of delivery to the original retail purchaser.
