RCA sockets Mk7 kit - Fitting instructions
Rev. 07/19
Thank you for choosing our RCA sockets kit, it is Designed and Made in Italy by Precision Sound Lab
using the best technologies and materials for superior performance and durability.
Our kit is designed to fit all the Technics SL-1200/1210 from Mk2 to Mk6 models.
This kit is not suitable for SL-1200 GAE/G/Gr and Mk7 models.
Worldwide Registered Design by Precision Sound Lab
WARNING! RISK OF ELECTRIC SHOCK
UNPLUG MAINS CABLE BEFORE STARTING
RCA SOCKET INSTALLATION
Technics is a brand of Panasonic Corporation, all rights reserved to the owner, use is only for reference.
