Summary of Contents for OmegaWatt Multivoies Pad
- Page 1 MULTIVOIES OmégaWatt User Manual Multivoie Pad Décembre 2014...
-
Page 2: Table Of Contents
MULTIVOIES OmégaWatt TABLE OF CONTENT OVERVIEW : ......................3 Home screen : ......................4 ADVANCED VIEW OF A CHANNEL: ................5 Waverforms ......................5 InitialiSe a Multivoies System: .................. 6 CLOCK SETTINGS ....................6 SET THE TIME PERIOD OF RECORDING ..............7 DATA FILE DOWNLOAD .................... -
Page 3: Overview
MULTIVOIES OmégaWatt 1 OVERVIEW : Multivoie Pad is a device with a touch screen directly plugged to a Multivoies sytem. It allows to configure the system, dump the data, and view real time measures. It provides a SD-card reader to dump the data in a tsv file, which can be read by any computer. -
Page 4: Home Screen
MULTIVOIES OmégaWatt 2 HOME SCREEN : This is the screen displayed at the start. It shows automatically the serial number and the name of the concentrator, the voltage of the 3 phases, the clock, the time period of recording and the serial numbers of all the modules detected. Show the serial number and the name of the concentrator, the voltage of the 3 phases and the recording period. -
Page 5: Advanced View Of A Channel
MULTIVOIES OmégaWatt 3 ADVANCED VIEW OF A CHANNEL: Browse between the modules Browse between the channels Shows the real time values. Display the channel name, touch to modify. The current phase is in red. Touch another number to apply a new phase. With compatible modules, pressing the «... -
Page 6: Initialise A Multivoies System
MULTIVOIES OmégaWatt 5 INITIALISE A SYSTEM: MULTIVOIES Once the connections are correctly set up, each channel phase must also be set. The « reconfig » button allows you to initialize the configuration: all the channels get crossed out. To set a channel, select it. The line concerning the phase is crossed out. After choosing a phase, the line is no longer crossed out. -
Page 7: Set The Time Period Of Recording
MULTIVOIES OmégaWatt 7 SET THE TIME PERIOD OF RECORDING In order to set the recording period of the Multivoies system, you need to press the concentrator information’s displayed on top of the screen. Simply select the new period in the frame and press ok. Note: With Multivoie system, data are continuously recorded. -
Page 8: Configuration Du Module Gprs
MULTIVOIES OmégaWatt 9 CONFIGURATION DU MODULE GPRS Note: Before using GPRS module, you must create the correct folder on the ftp server: "FTP folder set in GPRS module"\"Concentrator SN"\ </br>(example : \0002\01001224\) The GPRS module list must be up to date (button UPD. LIST) Main screen The first line shows you if the list of modules stored on the GPRS matches the ones of the... -
Page 9: Call Time Settings
MULTIVOIES OmégaWatt Call Time settings Set the hour with the help of the numeric pad. Upload frequency : -Once by day. -Twice a day: the second call occurs 12h after the first call. -Every hour: the call occurs on the minute set.
