Owner's Manual
OmniDry Wall & Cavity Drying System
Please Read and Save These Instructions
AC8400
Specifications
Other Specifications
Motor Specifications
Thermal protection in case of overheating due to
5.7 Inch/ 145mm, 2-Stage Tangential By-Pass
blocked intake.
120 VAC
106 Inches of water column – Vacuum
PVC (Vinyl) Tubing 3/8" ID x 1/2" OD
Over 2600 LPM – Air Flow
1200 Watts
Hose Barb Adapter 3/8" x 1/4" MPT
9.3 Amps
Double ball bearing construction
UL Recognized, Category PRGY8
Advertisement
Table of Contents
Summary of Contents for OmniPro OmniDry AC8400
- Page 1 Owner’s Manual OmniDry Wall & Cavity Drying System Please Read and Save These Instructions AC8400 Specifications Other Specifications Motor Specifications Thermal protection in case of overheating due to 5.7 Inch/ 145mm, 2-Stage Tangential By-Pass blocked intake. 120 VAC 106 Inches of water column – Vacuum PVC (Vinyl) Tubing 3/8”...
- Page 2 Warranty unless the customer has obtained a Return Material Authorization COMPANY’S LIABILITY FOR DAMAGES ARISING OUT (RMA). To get an RMA, call OmniPro Manufacturing at 800-637-3789 and ask for OF ITS MANUFACTURE OR SALE OF ITS EQUIPMENT the Returns Department, which will then issue an RMA number and will arrange...
- Page 3 WARNING Read operator’s instructions and Warnings before using this equipment. WARNING: Do not allow anything to cover the intake vent. Overheating the motor could damage the OmniDry Wall & Cavity Drying unit. CAUTION: Do not block the air output with anything other than the supplied plug-off system.
- Page 4 In order to achieve the best air pressure for wall drying, OmniPro Manufacturing recommends that the 3/8” ID vinyl hoses be cut as shown above. Lengthening the hoses will result in a loss of pressure unless the pressure is equalized by capping-off one or more of the hoses to compensate.
