infobit WP200-Kit User Manual

Multi-function av intelligent education system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WP200-Kit User Manual
No.
1
2
Connected the "Auto System" function description
Approval：
Date：
Revised summary description
Initial version
Approve by：
Date：
Record page
1
File No.
RD-I-20-012
Version
Effective Date
2020-01-06
Page
Revise
Version
person
1.0
Alex
V1.1
Alex
Issue：Alex
Date：2020/01/06
1.1
1 / 26
Revised
Date
2020-01-02
2020-01-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WP200-Kit and is the answer not in the manual?

Questions and answers

Related Manuals for infobit WP200-Kit

Summary of Contents for infobit WP200-Kit

  • Page 1 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 1 / 26 Record page Revise Revised Version Revised summary description person Date Initial version Alex 2020-01-02 Connected the “Auto System” function description V1.1 Alex 2020-01-06 Approval： Approve by：...
  • Page 2 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 2 / 26 Multi-function AV intelligent education system Model: WP200-Kit VER 1.1...

  • Page 3: Table Of Contents

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 3 / 26 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.

  • Page 4: Introduction

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 4 / 26 1. Introduction The product is a multi-function AV intelligent education system. It offers 2HDMI and VGA video extension, video switching, system control and analog audio amplification.

  • Page 5: Features

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 5 / 26 2. Features ☆ HDMI 1.4b, HDCP 2.2 and HDCP 1.4 compliant. ☆ Video resolutions up to 4K2K@30Hz, 1080p@120Hz and 1080P 3D@60Hz. ☆ Audio up to 7.1 channels of High Definition audio pass through (LPCM, Dolby TrueHD, and DTS-HD Master Audio).

  • Page 6: Specifications

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 6 / 26 4. Specifications Technical HDMI Compliance HDMI 1.4 HDCP Compliance HDCP 2.2/HDCP 1.4 Video Bandwidth 10.2 Gbps Video Resolution up to 4K2K@30Hz,1080P@120Hz and 1080P 3D@60Hz Color Space...

  • Page 7: Operation Controls And Functions

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 7 / 26 Operating 32 - 104°F / 0 - 40°C Temperature Storage Temperature -4 - 140°F / -20 - 60°C Relative Humidity 20 - 90% RH (no condensation) 5.
  • Page 8 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 8 / 26 Number Name Function description HDCP LED HDCP compliance indicator. ▪ OFF: HDMI input is not carrying HDCP content. ▪ ON: HDMI input is carrying HDCP content.

  • Page 9: Receiver Panel

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 9 / 26 5.2 Receiver Panel Number Name Function description MIC GAIN Set the MIC input gain. POWER LED System power indicator. LINK LED HDBaseT Link status indicator. ▪ OFF: No Link.

  • Page 10: Web Gui User Guide

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 10 / 26 2X30 watts @4Ω Connect to speaker out. DC 24V Connect 24V/3.75A adaptor to AC wall outlet for power supply. 6. Web GUI User Guide The product can be controlled via Web GUI through TCP/IP port. The default IP address is 192.168.2.100.
  • Page 11 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 11 / 26 MAIN page ① Shows the status of the input signal. Green: The input port has connected an active signal. Blue: The input port has connected success but it has not active signal.
  • Page 12 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 12 / 26 ② Volume control outputs for the amplifier and the audio extractor. Adjusting the slider to increase or decrease outputs for the amplifier and the audio extractor.
  • Page 13 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 13 / 26 CONTROL page ① Display System Sync: When the toggle is in ‘enable’ position, the display on/off subroutine will run the system subroutine on/off every time. (see section 7)
  • Page 14 RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 14 / 26 Auto System: When the toggle is in ‘enable’ position and the system is in standby status, if a new signal is connected, the system will change to active and fully controllable.When the toggle is in ‘disable’...
  • Page 15 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 15 / 26 The RS-232 communication settings for the RS-232 port. ⑥ RS232 On Command: Sends out data when Display On subroutine is called. RS232 Off Command: Sends out data when Display Off subroutine is called.
  • Page 16 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 16 / 26 INPUT/OUTPUT page ① Switch Mode: Sets how the switcher plate will change between input signals.
  • Page 17 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 17 / 26 it includes ‘Auto’ mode and ‘Manual’ mode. ② Sets the priority to use when the switch mode is set to priority mode. 1 is the highest priority and 3 is the lowest.
  • Page 18 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 18 / 26 EDID: The name of the current EDID. EDID Update: Upload a.bin file to change what EDID is stored in the device’s internal memory that is used when EDID is set to internal.
  • Page 19 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 19 / 26 ① The network settings of the device’s internal system. ② Room Label: This is the user-assigned label that appears at the top of the web interface.
  • Page 20 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 20 / 26 the firmware of the control panel and the receiver box, not the two-gang transmitter. To update the firmware of the two-gang switcher, use the USB port on the plate.
  • Page 21 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 21 / 26 When you set it over and you can click ‘Login’ button to enter Web GUI function page. The page likes below:...
  • Page 22 File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 22 / 26...

  • Page 23: System On/Off Subroutine

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 23 / 26 7. System ON/OFF Subroutine...

  • Page 24: Display On/Off Subroutine

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 24 / 26 8. Display ON/OFF Subroutine...

  • Page 25: System Reset

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 25 / 26 9. System Reset To perform a system reset hold the source button (SOURCE button) for 20 seconds until the HDCP light flashes three times. When the system is reset, user settings will return to their default values this includes: passwords, room label, switching mode, IP address, etc.

  • Page 26: Application Example

    File No. RD-I-20-012 Version Effective Date 2020-01-06 WP200-Kit User Manual Page 26 / 26 10. Application Example...
