Table of Contents

DMX016
Dmx512 – TTL Converter
User's Manual
Rev 1.0
Lumina Visual Productions reserves the right not to be responsible for the correctness, completeness or
quality of the information provided in this user's guide. Therefore Lumina Visual Productions cannot be
held liable for any damage caused through the use of the above specified information. Specifications are
subject to change without notice.
This user's guide, and all of its contents remain the Copyright of Lumina Visual Productions, and may not
be copied, reproduced or redistributed in any form without the express written permission of the author.
© 2005 Lumina Visual Productions. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMX016 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lumina Visual Productions DMX016

  • Page 1 Specifications are subject to change without notice. This user’s guide, and all of its contents remain the Copyright of Lumina Visual Productions, and may not be copied, reproduced or redistributed in any form without the express written permission of the author.
  • Page 2 The DMX016 ships to recognise a start code of ‘0’ as being valid. If you wish to use this device with a start code of something other than ‘0’, please advise us as we can also re-flash the microprocessor to provide for this.
  • Page 3 Connections The DMX016 has 4 headers for interfacing to your equipment. These are as follows: Outputs 1 - 8 Outputs 9 - 16 Power DMX512 Note: Pin 1 is designated by a square pad on the underside of the PCB. The dual row headers are pinned such that Pin 1 is the top left pad, pin 2 is to the right of pin 1, etc.
  • Page 4 Pin 2: Cold (Signal -ve) Pin 3: Ground Outputs The DMX016 has two 8 x 2 way headers to interface to your equipment. Each header has one row of pins connected to ground, with the other row being 8 of 16 available outputs.
  • Page 5 Note: Switch 1 has no effect unless it is used in conjunction with other switches. Ie, if switches 2 through 9 are off, the DMX016 will receive on channel 1 through 16 regardless of the position of switch 1.
