Atek MLC 410 Operational Manual

Magnetic linear encoders self aligned system
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
M
AGNETIC
• Self-bearing integrated ball system
• Magnetic measurement
• Contactless / non-friction system
• High tolerance to vibration and shocks
• Easy mounting with wide mounting tolerances
• Stroke up to 4 meters
• Resistant to dust, oil and moisture
• Robust aluminum body
• Excellent Stability
•
IP67 Protection Class
KK-MLC.008 26.02.2020 Rev No:1
L
E
INEAR
MLC 410
S
A
ELF
LIGNED
S
YSTEM
NCODERS
O
PERATIONAL
M
ANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MLC 410 and is the answer not in the manual?

Questions and answers

Related Manuals for Atek MLC 410

Summary of Contents for Atek MLC 410

  • Page 1 MLC 410 LIGNED YSTEM AGNETIC INEAR NCODERS • Self-bearing integrated ball system • Magnetic measurement • Contactless / non-friction system • High tolerance to vibration and shocks • Easy mounting with wide mounting tolerances PERATIONAL • Stroke up to 4 meters •...
  • Page 2 1. W ARNINGS 1. Connections must be completed by only authorized personnel. 2. Consider the warnings when completing the connections and using the scale. 3. Pay attention about the sensors power supply. (For TTL sensor max. 5V, for Push-Pull sensor max.
  • Page 3 This strain will affect the performance of the linear encoder and may lead to a reduction of accuracy or repeatability in the forming operation. In order to solve this problem is designed the MLC 410 incremental linear encoder, especially for press brake applications.

  • Page 4: Specifications

    3. T ECHNICAL PECIFICATIONS TECHNICAL Operating Temperature - 25 to 85 °C Storage Temperature - 40 to 100 °C Protection Class IP67 Body Aluminum Magnetic Tape Tape Reading Distance 2 mm Travel Velocity 3 m/s max. Connection D-Sub 9 Pin Socket , 5 or 8 x 0,14 mm shielded cable Accuracy ±...

  • Page 5: Power Supply

    4. C ONNECTIONS 4.1. Pin Connections In the following table the cable colors of sensors output signals are given. If the control circuit is suitable in the Line Driver sensors of the not output signals (/A, /B, /Z) have to be added to the system.
  • Page 6 4.2. Installing The proper installation of MLC 410 is very important issue in terms of the system work properly. The proper installation is shown down. Up surface of the sensor must be down for negative factors. Reader sensor and profile must be parallel for all the stroke.
  • Page 7 *Other Socket Connections S41 Socket S87 Socket Pin Number Cable Color Signal Pin Number Cable Color Signal POWER SUPPLY BLACK GROUND POWER SUPPLY YELLOW BLACK GROUND PINK BLUE GREEN YELLOW WHITE WHITE GREY GREY BLUE PINK GREEN S86 Socket S71 Socket Pin Number Cable Color Signal...
  • Page 8 A.S. ENSOR ECHNOLOGY  Tuzla Kimya Sanayicileri Org. San. Bolg., Melek Aras Bulvari No:67 TR-34956 Tuzla / Istanbul - TURKEY  Tel: +90 (216) 399 44 04  Fax : +90 (216) 399 44 02  Web: www.ateksensor.com  E-Mail: info@ateksensor.com KK-MLC.008 26.02.2020 Rev No:1...
