Auvs KR615 User Manual

Uv box germicidal enclosure
Hide thumbs Also See for KR615:
Table of Contents

Advertisement

Quick Links

KR615 "UV BOX"
Germicidal Enclosure
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KR615 and is the answer not in the manual?

Questions and answers

Related Manuals for Auvs KR615

Summary of Contents for Auvs KR615

  • Page 1 KR615 “UV BOX” Germicidal Enclosure User’s Manual...

  • Page 2: Table Of Contents

    Procedures for Disposal of UVC Blubs…………………………………………………...Page 14 Special Handling Information for Broken UVC Blubs…………………………………….Page 14 Repair and Maintenance…………………………………………………………….Page 15 Bulb and Rod Replacement…………………………………………………………Page 16 Cleaning the AUVS Germicidal Enclosure…………………………………………Page 17 Specifications and Warranty Information………………………………………………….Page 19 Warranty Card……………………………………………………………………………Page 20 Warnings and Precautions Symbols The exclamation point, within a circle, is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the device.

  • Page 3: Operating Information

    1) Clean visible dirt, mositsure or liquid residue from items to be disinfected as per manufacturer’s instructions. 2) Place item(s) in the AUVS Germicidal Enclosure (UV Box). For items with cords (or leads) that must remain connected, thread the cord through the unit’s Wire Routing System.

  • Page 4: Location Of Safety And Compliance Labels

    Location of Safety and Compliance Labels Advanced Ultra-Violet Systems is in compliance with various regulations, details of which are listed in the Specifications section. The AUVS Germicidal Enclosure safety and compliance label, shown below, is located on the right panel of the AUVS Germicidal Enclosure.

  • Page 5: Warnings, Precautions And Limitations For Use

    Warnings, Precautions and Limitations for Use Post-Disinfection Warnings WARNING: The AUVS Germicidal Enclosure is intended to disinfect mobile devices and non-critical medical devices. The subsequent utilization of the mobile devices and non-critical medical devices disinfected by the AUVS Germicidal Enclosure is the sole responsibility of the user.

  • Page 6: Safety Warnings And Precautions

    These materials are used for the envelopes of the UV-Box’s lamps. AUVS also uses a pure quartz material for the rods in the AUVS Germicidal Enclosure “UV Box” to eliminate obstruction of the UV-C light while supporting the objects that are being disinfected.
  • Page 7 PRECAUTION: The product must be used in accordance with this User’s Manuel. PRECAUTION: Avoid spilling fluids on any part of the AUVS Germicidal Enclosure. Do not place food or drink inside of the AUVS Germicidal Enclosure. For additional info please see intended use under Indications for Use.
  • Page 8 PRECAUTION: If spills do occur, immediately disconnect the AUVS Germicidal Enclosure from the power source and contact Technical Support (866-918-8546) for guidance on cleaning the AUVS Germicidal Enclosure. PRECAUTION: Never attempt to disinfect any objects other than mobile devices or non-critical medical devices. See intended use under Indications for Use.

  • Page 9: Voltage Warnings And Precautions

    Voltage Warnings and Precautions Older Models of the AUVS Germicidal Enclosure have no user-serviceable parts inside. Servicing to be performed by factory-authorized personnel only. Removal of labels, covers, or encasement fasteners voids the warranty. For servicing newer models of the AUVS Germicidal Enclosure, see Bulb and Rod Replacement.
  • Page 10 WARNING: To prevent fire or shock hazard, do not expose this device to rain or moisture. Do not submerge the AUVS Germicidal Enclosure in liquid of any kind. Do not spray liquids of any kind inside the AUVS Germicidal Enclosure. Do not put containers of liquid of any kind inside the AUVS Germicidal Enclosure.

  • Page 11: Cleaning Precautions

    Cleaning Precautions PRECAUTION: Refer to Cleaning the Enclosure for recommended cleaning of the AUVS Germicidal Enclosure. PRECAUTION: Apply cleaning agents to a clean, lint-free cloth first and then clean the device. Liquid sprayed or applied directly to the device could possibly leak inside and cause damage.

  • Page 12: Indications For Use

    UVC light applied at a known intensity and for a known duration. The intention is to allow the user to position their non-critical medical devices and small mobile devices inside the AUVS Germicidal Enclosure for disinfection process. Operation of the system is to take place outside of sterile fields and by personnel performing their duties outside of sterile fields.

  • Page 13: System User Safety Controls

    System User Safety Controls The AUVS Germacidal Enclosure has multiple safety controls and mechanisms to insure that users are safe and protected during the UVC disinfection operations. WARNING: Do not intentionally bypass any of the safety precautions built into the device. Failure to comply may result in exposing skin to UVC. Prolonged skin exposure may generate redness and an uncomfortable sunburn sensation.

  • Page 14: Procedures For Disposal Of Uvc Blubs

    Procedures for Disposal of UVC Blubs AUVS technology uses bulbs with lower mercury content than typical overhead lighting, and cleaning should follow the practices required by your facility and in accord with applicable regulations. As a guideline, if bulbs are broken, ventilate the area where the breakage occurred. Clean up with mercury vacuum cleaner or other suitable means that avoid dust and mercury vapor generation.

  • Page 15: Repair And Maintenance

    Testing UV Intensity Labels should be used to periodically test the effictiveness of the bulbs in your AUVS Germicidal Enclosure. These labels can be purchased from your local AUVS Sales Representative, or from Safety Net, LLC (866-918-8546). Please contact Safety Net, LLC for pricing and details.

  • Page 16: Bulb And Rod Replacement

    • First remove the access panel on the left side of the UV Box. (see figure A) • Carefully slide out the broken Quartz Rod. Be cautious of sharp edges. • Discard broken rod, making certain to remove all fragments from the inside of the AUVS Germicidal Enclosure. See: Cleaning the AUVS Germicidal Enclosure.

  • Page 17: Cleaning The Auvs Germicidal Enclosure

    WARNING: Always power off the system before cleaning. An electrical shock could occur if the device is powered on and liquid is spilled into it. To clean the OUTSIDE of the AUVS Germicidal Enclosure without physical or cosmetic degradation, use a clean, lint-free cloth moistened with one of the following: •...
  • Page 18 Cleaning Precautions PRECAUTION: Apply cleaning agents to clean lint-free cloth first and then clean the device. Liquid sprayed or applied directly to the device could possibly leak inside and cause damage. PRECAUTION: Allow the device to completely dry before operating again. PRECAUTION: Never use abrasive materials.

  • Page 19: Specifications And Warranty Information

    16,000 hours = 50+ years Bulb Life under normal use. The KR615 UV Germicidal Enclosure Device is warranted for two (2) years from the date of purchase. All parts and labor are covered under this period, excluding damage due to abuse by the user.

  • Page 20: Warranty Card

    UV Box Purchased From:___________________________________________________________ UV Box Serial Number: ____________________________________________________________ The KR615 UV Germicidal Enclosure Device is warranted for two (2) years from the date of purchase. All parts and labor are covered under this period, excluding damage due to abuse by the user.
  • Page 21 For Sales and Service, Please contact Safety Net, LLC www.safetynetamerica.com info@safetynetamerica.com 866-918-8546...
