TMI Products Save-T SCREEN-PRO Installation Instructions Manual

All season roll-up doors

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Spring Loaded

SCREEN-PRO

™

All Season Roll-Up Doors

IN-JAMB MOUNTING METHOD

INSTALLATION INSTRUCTIONS

READ THIS FIRST

Carefully examine the crate(s) for damage before opening. If the carton is damaged, immediately notify shipping

company. Open the carton(s) and remove all protective packaging. Retain the shipping carton(s) until the unit(s) is

installed and properly operating. TMI, LLC is not responsible for delayed or late claims.

Serial No: ________________ Model #: _______________ Date Purchased: ___________

Group of Companies

Table of Contents

Need help?

Do you have a question about the Save-T SCREEN-PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for TMI Products Save-T SCREEN-PRO

Page 1 Spring Loaded SCREEN-PRO ™ All Season Roll-Up Doors IN-JAMB MOUNTING METHOD INSTALLATION INSTRUCTIONS READ THIS FIRST Carefully examine the crate(s) for damage before opening. If the carton is damaged, immediately notify shipping company. Open the carton(s) and remove all protective packaging. Retain the shipping carton(s) until the unit(s) is installed and properly operating.
Page 2 Warning To Reduce the Risk of Injury, Observe the Following: • Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer. • Installation work must be done by a quali ed person(s) in accordance with all applicable codes and standards. •...
Page 3 STEP 1 Lay the basic components in front of the doorway opening. Guide Flare Using work horses will make the assembly process easier although it is not essential. Place the Guide Tracks with the Guide Flare facing up. Right Guide Guide Track Flare...
Page 4 STEP 5 Sheet Metal Screws Remove the Mounting Angles and drill the holes in the Guide Tracks. Replace the Angles and secure them using self-tapping sheet metal screws. STEP 6 IMPORTANT The Guide Track Flare Plate ships flat and must be bent out 1 ”...
Page 5 STEP 8 Drum Mounting Plate Drum Mounting Plate (Bearing Side) (Spring Side) Bottom Hole Bottom Hole Attach a Drum Mounting Plate to (Set 1) (Set 2) the top of each Track Guide using 5/16'' x 1-1/4'' bolts with flange nuts. The square cradle (spring side) goes on the left and the round cradle (bearing side) is on the right.
Page 6 The Bottom Edge of the Screen facing down. Square Cradle Bottom Edge of Screen facing down Cotter Round Cradle Once the shaft is in both cradles, place a Cotter Pin through the square shaft and cradle to secure it (left side). STEP 12 With the Screen Roller Drum in place, remove the Spring Locking Clip.
Page 7 STEP 15 STRAP PLACEMENT The final steps are attaching the Rollover Straps and Lock Down Straps. Guide Tracks NOTE: The “D” Rings, Pull Straps and Slide Handles are attached at the factory. Also, one end of the Rollover Straps is Footman Footman Loops...
Page 8 ADDING TENSION TO THE SPRING If after testing the door movement, the spring Spring Locking Clip needs more tension, the following procedure should be taken. First, remove the assembly from the doorway opening. Cradle Lock Cotter Plate Stabilize Roller Drum Cradle Then, with the Roller Strap...
