- Page 1 Operational Maintenance & Service Bulletin for Models: NHPL-1833-ECOC-2D-DGT NHPL-1836-ECOC Non-Insulated Economy NHPL-1836C-DGT NHPL-1836C Non-Insulated Standard NHPL-1825-UNC-DGT NHPL-1825-UNC Non-Insulated Universal Runner NHPL-1810/HHC Non-Insulated Undercounter 1/2 size INHPL-1836C-DGT INHPL-1836C NHPL-1836C-DGT NHPL-1825-UNC Insulated 100% Pre-Tested Electrical Assembly o r k...
-
Page 2: Table Of Contents
General Information Models: NHPL-1833-ECOC-2D-DGT NHPL-1836-ECOC NHPL-1836C-DGT NHPL-1836C NHPL-1825-UNC-DGT NHPL-1825-UNC NHPL-1810/HHC INHPL-1836C-DGT INHPL-1836C TABLE OF CONTENTS General Information ......................1 Unpacking and Installing ....................1 Maintenance and Caution ....................1 Power Supply ........................1 Operating Instructions Digital Drawer ................2 Alarms and Conditions ....................6 Operating Instructions Analog Controls .............. -
Page 3: General Information
If so, notify the carrier immediately to file a damage claim. All WinHolt equipment is carefully tested and inspected prior to shipment. When accepted for delivery by carrier, the responsibility for safe arrival at the destination is assumed by the carrier. -
Page 4: Operating Instructions Digital Drawer
Humidity Setpoints are stored and will be used the next time “PROOF” mode is entered. NOTE: Box Temperature Setpoint limits are the same in “PROOF” mode as in “HEAT” mode. The user could set a high box temp even though the humidity setpoint is low. winholt eq u ip men t 800.444.3595 fax: 516.222.0371... - Page 5 “N” Indexed Format Box Temperature Setpoint Table “N” °F °C 80.00 26.67 93.75 34.31 107.50 41.94 121.25 49.58 135.00 57.22 148.75 64.86 162.50 72.50 176.25 80.14 190.00 87.78 °/”N” 13.75 7.64 winholt e quipm e nt www.winholt.com fax: 516.222.0371 800.444.3595...
- Page 6 Throughout this document, humidity refers to the Water Pan Temperature, since humidity is not directly sensed. In “HEAT” mode, “---“ is displayed. The Humidity Setpoint ranges from 1.0 through 9.0 with a resolution of 0.5. See Table 2. winholt eq u ip men t 800.444.3595 fax: 516.222.0371...
- Page 7 When being adjusted, Setpoint(s) will remain flashing for 5 seconds while adjusting. After adjusting a steady display will show actual conditions. Note: Humidity Setpoint may be set only in “PROOF” mode, not in “HEAT” mode. winholt e quipm e nt www.winholt.com fax: 516.222.0371...
-
Page 8: Alarms And Conditions
• Firmware Version 0.4 adds the option to view the Control’s Firmware Version on the 3-digit displays. Turn the unit “OFF” by holding the “POWER” button, then hold both “POWER” and winholt eq u ip men t 800.444.3595 fax: 516.222.0371... - Page 9 No AC Line Interrupt 60 Hz (16.67 ms “Err” “AC ” AC interrupt Timed relay operations interval) interrupt has are suspended; relay not occurred within operations lose AC 50 ms line synchronization winholt e quipm e nt www.winholt.com fax: 516.222.0371 800.444.3595...
-
Page 10: Operating Instructions Analog Controls
“Proof Temperature”. The heat controls in the cabinet range from low heat approx. 80 °F to high heat, approximately 185 °F. The humidity controls in the cabinet range from approximately 20% to 100% relative humidity. humidity. The average will be approximately 85% relative winholt eq u ip men t 800.444.3595 fax: 516.222.0371... -
Page 11: Recommended Temperature Guidelines-Food Holding Chart
Roast Beef Uncovered 170 - 180 Roast Pork Uncovered 170 - 180 Strip Steak Uncovered 160 - 170 Turkey Uncovered 170 - 180 Vegetables Mixed Covered 170 - 175 Waffles Covered winholt e quipm e nt www.winholt.com fax: 516.222.0371 800.444.3595... -
Page 12: Drawer Assembly And Parts
NHP-PD-DGT 650484 Door Gasket for 1836 Series NHPL1836-DR GSKT Digital Drawer Replacement Door Lexan 657459 NHPL-DR/UN Universal Runner Replacement Door Lexan (15) 657432 NHPL-DR/HH Mini Half Height winholt 233656 Plastic Door Handle H-323-2 equi p ment 800.444.3595 fax: 516.222.0371 www.winholt.com... -
Page 13: Electric Schematic Power Supply Nhp-Pd-Dgt Digital
Electric Schematic Power Supply Digital Drawer NHP-PD-DGT winholt e quipm e nt www.winholt.com fax: 516.222.0371 800.444.3595... -
Page 14: Electric Schematic Power Supply Nhp-Pd-Eco Analog
Electric Schematic Power Supply (continued) Analog Drawer NHP-PD-ECO winholt eq u ip men t 800.444.3595 fax: 516.222.0371 www.winholt.com... -
Page 15: Universal Runner Assembly Instructions
THE CABINET SIDE THE RUNNER WILL SLIDE OUT EASILY. DO NOT FORCE IT WHEN IN THE CORRECT POSITION THE RUNNER SHOULD BE AT 90 DEGREES TO THE SIDE OF THE CABINET. winholt e quipm e nt www.winholt.com fax: 516.222.0371 800.444.3595... -
Page 16: Statement Of Warranty & Troubleshooting
Wrappers be free from defects in material or factory workmanship, under ordinary use for the purpose for which it is designed, for a period of (1) year from the date of shipment from the Winholt facility. Equipment will at our option be repaired or replacement part(s) furnished F.O.B.
