- Page 1 Welcome to your Camera...
-
Page 2: Table Of Contents
Contents Introduction to Your Camera ......2 Features ................2 Components ..............4 Installing the Product ......... 7 Launching the App ..........10 Mounting on the Wall ........13 Specifications ............. 15 Works with SmartThings ........17... -
Page 3: Introduction To Your Camera
Introduction to Your Camera This SmartThings Cam can monitor your home and then alert any suspected motions in real time. Features • Standalone system: Equipped with CPU and video encoder for operation, which requires only power and network connections. • HD video: Supports up to 1080p HD video with H.264 encoding. - Page 4 Introduction to Your Camera • 2 IR LEDs: Can provide illumination up to 5 meters away for better video quality. • High dynamic range (HDR): Balances the illumination for clear image quality. • Motion detection zone: Can be changed by dragging or tapping areas for motion monitoring.
-
Page 5: Components
Introduction to Your Camera Components Front panel Status LED IR LEDs IR LEDs Microphones Microphones Lens Light Sensor Component Description Status LED Off: No power supplied Blue On: Power supplied Slow blinking of Blue: Booting in progress Fast blinking of Blue: Rebooted with default settings... - Page 6 Introduction to Your Camera Component Description Status LED Green On: Wireless network connected Fast blinking of Green: Data communication in progress Amber On: Firmware upgrade failed. Then the camera reboots after 5 seconds Fast blinking of Amber: Camera available for softAp or QR scan Blinking of Blue and Amber: Upgrading the firmware Lens...
- Page 7 Introduction to Your Camera Rear panel Reset Button Power Plug Stand Mounting Plate Component Description Power Plug Connect the power adapter here. Never use other adapters Reset Button Press for over 10 seconds to restore the factory default settings. Then the system reboots with the default values.
-
Page 8: Installing The Product
Installing the Product Installing the Product When the product is ready, install it by keeping the following procedure: Check the following items are included in the package including this user guide. Determine the location to install the product. - Page 9 Installing the Product Connect the power plug into the camera and then plug the power connector into the outlet to supply power. Never use power adapters other than the provided one. It may cause damage to the system. The status LED blinks (approx. 1 minute) in amber during startup.
- Page 10 Download the SmartThings app for Android or iOS, create an account, and follow on-screen instructions to add the device. Use the SmartThings app to scan the QR code at the bottom of the stand and then follow on- screen instructions to finish setup.
-
Page 11: Launching The App
Launching the App When you launch the app after all things are made, the main screen appears on your mobile device. For monitoring, select the desired site on the screen. Then the following live view screen appears. - Page 12 Launching the App Description When clicked, the following menus appear: • My Info: Moves to the subscription page. You can subscribe to the premium service at Samsung.com. • Edit: Can edit the device information. • Settings: Moves to the camera plug-in settings page.
- Page 13 Premium Plan Free of charge $7.99 per month or $79.99 per year Can connect up to 2 Can connect up to 5 SmartThings cameras SmartThings cameras Can customize the Can customize the motion motion detection zones detection zones Can clip the recording...
-
Page 14: Mounting On The Wall
Mounting on the Wall The camera is usually mounted on the wall for permanent installation. In this case, follow the steps below: Remove the mounting plate from the stand by sliding it forward from the stand. Hold the mounting plate at the desired location and mark the holes for two mounting holes. - Page 15 Mounting on the Wall Align two mounting holes on the camera stand with two pilot holes and then mount the plate on the wall surface with two provided screws. Slide the camera stand onto the mounting plate until it clicks in place. Insert the power cable into the hole of the stand, connect the cable to the camera, and plug the power adapter into the outlet.
-
Page 16: Specifications
Specifications Power Adapter input: 100-240 V AC, 50/60 Hz Adapter output: 12 V DC, 1 A Color White Sensor ½. 7" CMOS sensor Dimensions 3.98” x 1.82” x 1.72” (101 mm x 46.3 mm x 43.7 mm) (H x W x D) Operating 32 °F to 104 °F tempera... - Page 17 Specifications Viewing angle 145° diagonal (Dewarping FOV is to be updated later) Night vision Built-in IR LEDs for night-time illumination (range within 5 m) IR LEDs LED type 1 tri-color LED (power/network/status) Connectivity Wi-Fi 802.11b/g/n, 2.4 GHz/5 GHz (WPA & WPA2 encryption supported) Wireless interface IEEE 802.11ac, 802.11b/g/n Vision Intelligence...
-
Page 18: Works With Smartthings
Works with SmartThings SmartThings works with a wide range of connected devices, including lights, cameras, locks, thermostats, sensors, and more. To purchase a device to connect to your product, be sure to check the Works with SmartThings label.
