V0.2

3922 496 32081

Rebuild Instruction UKA 3G Fiberadapter

Description:

Instruction for adapting the 3G Fiber Adapter LDK5420/** for use

with the

UKA Upgrade Kit Fiber 3922 407 62881 consists of:

1X Rebuild Instruction

1X Assembled DockPlate unit

3X Washer M3

2X Guide Pin

Type Sticker

Tools needed:

Standard set of Torx Screwdrivers

Coax Removal Tool (8122 407 01631)

PC or Laptop with LDK Scripter 7.0 (or 7.3 when using the JTAG Dongle)

Package needed:

Package 3922 407 .....

Available on the

Precautions:

Take sufficient ESD precautions

Do not open the adapter when it's connected via Fiberhybrid Cable to a Basestation.

Only trained and qualified personnel are allowed to perform this Rebuild.

Xenz

Camerahead.

Grass Valley Knowledge Base

Breda, August 2012

Page-1

Need help?

Do you have a question about the LDK5420 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for GRASS VALLEY LDK5420 Series

Page 1 PC or Laptop with LDK Scripter 7.0 (or 7.3 when using the JTAG Dongle) Package needed: Package 3922 407 ..Available on the Grass Valley Knowledge Base Precautions: Take sufficient ESD precautions Do not open the adapter when it’s connected via Fiberhybrid Cable to a Basestation.
Page 2 Rebuild Instruction Removal of dockingplate and interconnection board. Step 1: Remove the Left and Right Cover Step 2: Remove the HS Output Board. Unplug the Coax connector X6101 with the help of the Coax Removal Tool. Unplug the Coax connector X6101 with the help of the Coax Removal Tool. Unplug the Coax connector X6101 with the help of the Coax Removal Tool.
Page 3 Step 4: Remove the Dockingplate, unplug the Fanconnection from X32 Motherboard. Step 5: Remove the Fanunit with Damper from the Dockingplate. The Fanunit will be re-used. Step 6: Remove the Cooling Block by unsrcewing the six screws. Page-3...
Page 4 Step 7: Disconnect the three ﬂ exes X111, X112, X113 Disconnect the three ﬂ exes X111, X112, X113 X113 X112 X111 Step 8: Disconnect the Powercord from the motherboard. Unscrew the Bottom Printrail. Step 9: Remove the Printrail. Disconnect the Microphone Cable (X115) fi rst. Remove the Interconnection Board.
Page 5 Assembling the Adaptor with the new Dockingplate and UKA board Step 10: The new Dockingplate with Adaptor board Power Cable Flexes UKA Adaptor Board Microphone Connector Step 11: Mount the Fan with Damper in the new Docking Plate. Page-5...
Page 6 Step 12: Re-route the Coax for TP-out. Disconnect the Coaxconnecter with the Coax Removal tool. Place the connector as in the foto. Carefully pull the coax-cable into the back of the adapter. Old routing Old routing New routing New routing Page-6...
Page 7 Step 13: Mount the Bottomrail, place the included three Washers underneath. Step 14: Place the new Dockingplate in front of the adapter. Screw the two new Docking Pins into the adapterhousing. Connect the Audio Cable to X115 Page-7...
Page 8 Step 15: Connect the Powercable to X114. Page-8...
Page 9 Step 16: Connect the Fancable to X32 View from the left side. Page-9...
Page 10 Step 17: Put the Dockingplate Top in the slide. Step 18: Close the Dockingplate. Make sure the end of the three ﬂ exes are on the motherboard side. Connect the three ﬂ exes (X111, X112 and X113) Page-10...
Page 11 Step 19: Fasten the Dockingplate. Fasten the Dockingplate with the four screws. Look inside for correct mounting. (without the HS-Output Board installed). Step 20: Install the HS Outputboard. Connect the Coaxcable to X6101. Check the routing for all Cables. Page-11...
Page 12 Step 21: Mount the Coolingplate with the six screws. Place the rightside and leftside cover. Step 22: New Package Download. Step 23: Testing the System. Page-12...
Page 13: Grass Valley Product Support
Grass Valley Product Support Web-based support is available for many Grass Valley products. For software updates, our FAQ (Frequentely Asked Questions), or technical assistance, please contact us by e-mail or phone. Refer to: http://www.grassvalley.com/support/contact/broadcast for more information. Overview: For the overview of all released camera SI’s with corresponding fault description, updates and filters, see the excel-sheet on our knowledgebase.
