Kova 65M90T0 Install Instructions & User Manual

24-in digital-control wall oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Install Instructions
& User Guide
Product
24-in Digital-Control Wall Oven
Model Number
65M90T0 / K0000002047
Read these instructions completely and carefully. Save these instructions for
local inspector's use. Observe all governing codes and ordinances.
Note to Installer – Be sure to leave these instructions with the Consumer.
Keep these instructions for future reference. Product failure due to improper
installation is not covered under warranty agreement.
kovaproducts.com
Rev. 1.1 | 2019.10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65M90T0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kova 65M90T0

  • Page 1 Product 24-in Digital-Control Wall Oven Model Number 65M90T0 / K0000002047 Read these instructions completely and carefully. Save these instructions for local inspector’s use. Observe all governing codes and ordinances. Note to Installer – Be sure to leave these instructions with the Consumer.
  • Page 3 ACKNOWLEDGMENT Thank you for purchasing our product. We hope you enjoy using the many features and benefits it provides. Before using this product please study this entire Instruction Manual carefully. Keep this manual in a safe place for future reference. Ensure that other people using the product are familiar with these instructions as well.
  • Page 4  If the surface is cracked, switch off the appliance avoid the possibility of electric shock. User Servicing – Do not repair or replace any part of the  appliance unless specifically recommended in the manual. All other servicing should be referred to a qualified technician.
  • Page 5 Wear Proper Apparel – Loose -fitting or hanging garments  should never be worn while using the appliance.  Accessible parts may become hot during use.  An all-pole disconnection means must incorporated in the fixed wiring in accordance with the wiring rules.
  • Page 6 Use Care When Opening Door – Let hot air or steam escape before removing or  replacing food. Placement of Oven Racks – Always place oven racks in desired location  while oven is cool. If rack must be moved while oven is hot, do not let potholder contact hot heating element in oven.

  • Page 7: Safety Hints

    SAFETY HINTS Do not use the oven unless you are wearing something on your feet. Do not touch the oven  with wet or damp hands or feet. For oven: Oven door should not be opened often during the cooking period. ...

  • Page 8: Product Description

    PRODUCT DESCRIPTION Symbol Function description Oven Lamp: Which enables the user to observe the progress of cooking without opening the door. Oven lamp will light for all cooking functions. Defrost: The circulation of air at room temperature enables quicker thawing of frozen food, (without the use of any heat).
  • Page 9 OPERATION INSTRUCTIONS 1. Clock Setting After connecting the unit to the power, the symbols " 0:00 " will be visible on the display. 1> Press " ", the hour figures flashes. 2> Press " " to adjust the hour figures, (time should be within 0--23). 3>...
  • Page 10 5. Child lock Function To Lock : press " " and " " simultaneously for 3 seconds, there will be a long " beeping " sound and the " " will be illuminated. Lock quitting : press " " and " "...
  • Page 11 9. Energy-Saving Function 1> In standby mode and reminding state , press " " for three seconds, the LCD display will go off and set to energy-saving mode. 2> If no operation in10 minutes under standby mode, the LCD display will go off and go into energy-saving mode.
  • Page 12 ACCESSORIES Wire shelf : For grill, dishes, cake pan with items for roasting and grilling. Slider bracket : For cooking larger size food, these shelf support rails on the right and left sides of the oven can be removed, dishes and tray can be put on the oven floor, using functions as Radiant grilling, Double grilling, Double grill with fan.

  • Page 13: Shelf Placement Warning

    SHELF PLACEMENT WARNING: To ensure the oven shelves operate safely, correct placement of the shelves between the side rail is imperative. Shelves and the pan only can be used between the first and fifth layers. The shelves should be used with the right direction, it will ensure that during careful removal of the shelf or tray, hot food items should not slide out.

  • Page 14: Ventilating Openings

    VENTILATING OPENINGS When cooking is finished or in pause state or in standby mode, if the oven's center temperature is over 160 degree, the cooling fan will continue working for 15 minutes. Or when the oven's center temperature becomes lower than 160 degree, the cooling fan will stop in advance. Ventilating openings CONNECTION OF THE OVEN Be sure your appliance is properly installed and grounded by a qualified technician.
  • Page 15 Wire Branch Circuit Ungrounded Neutral Refer to Figure : • Disconnect ground from neutral at free Cable from power supply end of conduit. Junction box • White wires Connect the green GROUND wire from the oven to the GROUND wire in the Red wires junction box (bare or green colored wire).

  • Page 16: Installation

    Important: Use twist-on connector From power supply with square-wire spring Terminal Block From the oven Square-wire spring INSTALLATION min. Remark: 1.Only plus deviations are admissible for all dimension. 2.The cabinet is not include the power switch or socket. NOTE: The number of accessories included depends on the particular appliance purchased.
  • Page 17 REMOVING THE DOOR FROM OVEN (OPTIONAL) Removable door allows full access to entire interior of the oven for easier and quicker maintenance. To remove the door, open the door to the maximum angle. Then pull the buckle at the door hinge backward. (Figure 1) Figure 1 Close the door to an angle approximately 15°.

  • Page 18: Cleaning And Maintenance

    CLEANING AND MAINTENANCE For the sake of a good appearance and reliability, keep the unit clean. The modern design of the unit facilitates maintenance to a minimum. The parts of the unit which come into contact with food have to be cleaned regularly.
  • Page 19 USER INSTRUTIONS Each appliance shall be provided with an instruction manual that shall specifically warn the user of potential risks of fire, electric shock, or injury to persons, and state the precautions that should be taken to reduce those risks. These instructions shall be separated in format from other instructions, and shall appear before the operating instructions in the manual.
